10A 12V 24V Solar Panel Battery Regulator Auto Switch Charge Controller

Description :

10A 12V 24V Solar Panel Battery Regulator Auto Switch Charge Controller

Features :

Load operating modes: Pure light control, Light control+timing, Manual control, Debug mode, Normally open mode.
Protection Function: Load current protection, Low voltage protection, Overvoltage protection, Lightning protection.
Using PWM charging method to charge storage battery, extend the battery life.
Parameter setting has Power-down save function, both system mode and control parameter save in the chip, power off without distortion, adjust more convenient.

Visualized LED luminescent tube indicates current storage battery condition, digital tube display adjustable parameter, let users know the system using condition.
One key to set all procedure, easy to use.

Specification :

Voltage: 12V / 24V
Current: 10A
Color: Black
Weight: 150g
Package Weihgt: 187g
Size: Approx. 13.3 x 7 x 3.3cm

System connecting method:
1. First connect the storage battery, then connect solar panel, last the load(Light).
(Note the positive and negative, do not reversed.)
2. Disconnecting is use the opposite way, first split the load, and then split the solar panels, the final demolition of the battery.
3. Using thick cable to connect the controller and storage battery, the storage battery close to the controller.
4. The controller can not be directly connected to the inverter, the inverter and the battery must be connected.
5. When the controller is connected DC load, DC load and battery voltage must be consistent, otherwise easily lead to load, can not be used or directly burned.
6. Battery voltage can not too low, or can not properly charged, 12V battery voltage can not be less than 10.8V, 24V battery voltage is not less than 21.6V.
7. 12V system: rated working voltage of 12V, maximum output power of 120W, photocells rated working voltage 17V, the controller's maximum input power 170W.
8. 24V system: rated working voltage of 24V, maximum output power of 240W, photocells rated working voltage 36V, the controller's maximum input power 180W.

Package includeds :

1 x Solar Controller
1 x User Manual
