Tokina 11-28mm f/4 PRO DX Wide Zoom Camera Lens

Wide Zoom Range

The Tokina AT-X 12-28 PRO DX lens has a super-wide to standard zoom range while maintaining a constant fast f/4 aperture. This makes it a very versatile lens for different photo applications such as scenery, street scenes photography and event coverage. The lens is designed for DSLR cameras with APS-C (DX) sized sensors.

Aspherical and Super-low Dispersion glass elements

A new optical design using aspherical elements and super-low dispersion glass matches even the highest megapixel DX sensors cameras available today.

One aspherical lens element is positioned in the front group. This together with another precision moulded glass aspherical lens element placed in the rear group ideally focuses marginal light rays and maintains sharpness at the edges while also correcting distortion. The use of two different SD (Super-low Dispersion) glass elements, type FK01 and FK03, corrects chromatic aberration. The combination of all these specialised elements in the optical design yield excellent sharpness and colour.

New auto focus mechanism

The new AF 'GMR magnetic precision' control sensor is capable of fast auto-focus. Tokina placed the new sensor close to the drive unit in the lens for faster communication between the controller and AF motor. This combined with the motor's high-precision focus control yields faster, more accurate auto-focus.

Additionally, a brand new 'SD-M' (Silent Drive-Module) has greatly lowered the sounds emitted by the auto focus drive system allowing for much quieter AF. Both Canon and Nikon mounts have a built-in AF motor to make them auto-focus compatible with all current camera bodies.

Compact body design

The Tokina AT-X 12-28 PRO DX compact design makes the lens easy to carry and handle. Manual focus is achieved through Tokina's one-touch focus clutch AF/MF mechanism. Simply slide the manual focus ring forward for auto-focus or back for manual focus operation. The lens focus ring is damped in the manual mode for smooth and precise focusing.

In addition the lens has a 77mm filter size allowing filters such as the low-profile circular polarizer or UV to be used.

Specifications:

- Focal Length: 12 - 28mm, Comparable 35mm Focal Length: 19 - 45 mm

- Aperture:

Maximum: f/4

Minimum: f/22

- Camera Mount Type: Nikon F

- Sensor Size: APS-C

- Angle of View: 99o 37' - 54o73'

- Minimum Focus Distance: 9.84 Inch (25 cm)

- Maximum Reproduction Ratio: 1:5

- Elements/Groups: 14 / 12

- Diaphragm Blades: 9

- Autofocus: Yes

- Filter Thread: Front 77 mm

- Dimensions (DxL): Approx. 3.31 x 3.55 Inch (84 x 90.2 mm)

- Weight: 1.17 lb (530 g)

- Image Stabilisation: No

- Autofocus: Yes

- Tripod Collar: No

In the Box:

- Tokina 12-28mm f/4.0 AT-X Pro DX Lens

- BH-77B Lens Hood

- Front Lens Cap

- Rear Lens Cap
