These meters can be easily plugged in-line, to measure:Amp Hours (Ah) - Total charge Ah delivered from source to load. Amp Peak (Ap) - Highest amp value delivered (typically start up cycle for inverters, compressors, fridges etc).

Can also measure Amp (A) - Amps being delivered at that point in time.Voltage - Source voltage, and minimum Source voltage. Power (Watts) - Peak watts, Watts being delivered at that point in time.

Measures 0 to 200A with a resolution of 0.01A (50 Amp connectors for continuous - up to 200A for short peak bursts only)

Clear yellow backlit LCD display.

Operates from 8V to 60V.

Measures 0 to 60V with a resolution of 0.01V.

Measures 0 to 6554W with a resolution of 0.01W.

Measures 0 to 65Ah with a resolution of 0.001Ah.

High quality all-in-one meter.

Fitted Anderson plugs for easy connecting.

Ideal for the 4x4 and camping enthusiast.

Microprocessor controlled produces extremely precise and accurate readings.

describe:

• Operating Voltage: 8-60V DC
• Type: 200A Max
• Housing Material: ABS Plastic
• Dimensions(W+D+H): 83mm x 42mm x 24mm
• Weight: Approx 0.2kg
• 1x 200A Watt Meter(does not include other things in the picture)
• 1x User Manual
