Description:
Low voltage protection
Over current protection
Overheat protection
Short circuit protection
Reverse connection protection
Specification:
Dimension: Approx. 21 x 16 x 8.7cm/8.27 x 6.30 x 3.43''
Clip Wire Length: 60cm
Power Cable Length: 120cm
Input Voltage: 110V-250V
Output Voltage: 12V/24V
Frequency: 50-60HZ
Plug: US Plug
Application: best suitable for 400AH lead acid batteries(including wet and dry)
Introduction of 5-stage mode:
No-load Mode: when there has no load connected with charger, the LED Screen will show voltage only, the power is about 2W;
Constant Current Mode: means the battery voltage is lower than the set voltage of charger, then the charger supply constant charging current to maintenance both battery and battery charger;
Constant Voltage Mode: advanced pulse width modulation (PWM) technology, control the charger’s current and output voltage accurate, avoid overcharge;
Float Charge Mode: when the battery is going to be charged full,the charger will stop charging,but still supply constant floating voltage and small current to battery;
Trickle Charge Mode: when the battery voltage and current is approaching the set voltage and current, it will turn to trickle floating charge from automatic mode, it means charge full, also can be charged with floating mode.
Package Included:
1 X Car Battery Charger
1 X Power Charger
2 X Clip
1 X User Manual
Return policies :We 100% support our customers, If you are not satisfied or you have any problem with our products, please CONTACT US at once. We will help you free return the goods.
Warranty policies: Our products have 180 days warranty.
