3 Port 4K HDMI Switcher with IR Remote Control
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
Collect 19 Everyday Rewards points
Collect 19 Everyday Rewards points
Note: Does not feature Voice Control
Features:
• HDCP 2.2/1.x and DVI 1.0 compliant
• Support 18Gbps video bandwidth
• Supports 10 bits HDR pass through
• Support video resolution up to 4K2K@50/60Hz YCbCr 4:4:4
• Support 3D video format
• Low power consumption
• Support IR remote control and panel button control
Â
Package:
Technical | |
HDMI Compliance | HDMI 2.0b |
HDCP Compliance | HDCP 2.2 and HDCP 1.4 |
Video Bandwidth | 1 Gbps |
Video Resolutions | up to 4K2K@50/60Hz(YUV4:4:4),4K2K@30Hz,1080P@120Hz, and 1080P 3D@60Hz |
Color Space | RGB Â YCbCr 4:4:4, YCbCr 4:2:2 |
Color Depth | 1 -bit, Â 10-bit |
HDMI Audio Formats (Pass-through) |
LPCM Â 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Â Master Audio, DTS:X |
ESD Protection | Human  body model — ±8kV (air-gap discharge) & ±4kV (contact discharge) |
Connections | |
Inputs | 3x HDMI Type A [19-pin female] |
Outputs | 1x HDMI Type A [19-pin female] |
Mechanical | |
Housing nbsp; | Plastic Enclosure |
Color | Gray |
Dimensions | 1 0mm [W] x 79mm [D] x 16mm [H] |
Weight | 2 0g |
Power Supply | Input  AC100 - 240V 50/60Hz |
Output DC 5V/1A (US/EU standards, CE/FCC/UL certified) | |
Power Consumption | 1W  (Max) |
Operation Temperature | 32 - 104°F / 0 - 40°C |
Storage temperature | - - 140°F / -20 - 60°C |
Relative Humidity | 20 - 90% RH (no condensation) |
3 Month Warranty
GTIN: 9351634026784
Estimated Delivery Time Frame:2-10 Business Days
Ask a Question About This Product
Reference ID: 7343626
