A2120DT

120W A-2000D Series 100v ( only )mixer amplifier with Tones

The A-2000D series is a range of high performance digital mixer power amplifiers suited for broadcasting paging and/or background music in schools, retail shops, offices, factories, houses of

worship and large function rooms.

The A2120DT Mixer Power Amplifiers is designed to be a highly cost effective solution to the demands of PA applications.

The A2120DT has 6 tones via contact trigger ( Chime, Bell, Evac, Alert, Lockdown and all clear )

. The A-2000 series makes available a wide range of power outputs (A-2030D: 30W, A-2060D: 60W, A-2120D: 120W, A-2240D: 240W), with a frequency response of 50 - 20,000 Hz and distortion under 1%.

Three balanced/XLR3-31 type MIC inputs and two unbalanced/RCA pin jack AUX inputs, along with high impedance balanced (floating) speaker outputs and unbalanced REC outputs ensure operational versatility.

Phantom power and Vox muting are available on MIC 1, along with tone control for bass and treble.

Power, signal and peak indicators are provided.

All 2000D Series Mixer Amplifiers Feature:

100 volt, output
3 balanced XLR microphone inputs with phantom power onmic 1
Vox muting on mic 1
6 tones via contact trigger ( Chime, Bell, Evac, Alert, Lockdown and all clear )
Bass and treble control with boost and cut
50Hz to 20kHz frequency response
240VAC or 24VDC operation
Rack mountable with MB25B brackets
3 year warranty

Specifications

MODEL	A2120DT
Power Source	220 - 240V AC, 50/60 Hz
Rated Output	120 watt
Power Consumption	34W (AC operation at 1/8 maximum output without clip)
Frequency Response	50 - 20,000Hz (±3dB)
Distortion	Under 1% at 1 kHz, 1/3 rated power
Input	MIC 1 - 3: -60dB, 600, Balanced, 3P XLR AUX 1, 2: -20dB, 10 k, Unbalanced, RCA pin jack
Output	Speaker out: Balanced (Floating) High Impedance: 83 (100V) Rec out: 0 dB*, 600, Unbalanced, RCA pin jack
Tones	6 tones via contact trigger ( Chime, Bell, Evac, Alert, Lockdown and all clear )
Phantom Power	DC +21V (MIC 1)
Signal to noise ratio	Over 60dB
Tone Control	Bass: ±10dB at 100Hz/Treble: ±10dB at 10kHz
Muting	MIC 1: Mutes other input signals by 0 - 30dB attenuation
Indicator	Power LED, peak LED, signal LED
Dimensions	420 (W) × 100.6 (H) × 280.3 (D) mm
Weight	4.6 kg
*0dB = 1V	_
