PRVB20-BV20

Pressure Reduction Valve Boundary

The PRVB is designed to limit the water pressure to a domestic dwelling to around 500 kPa. When water supply is flowing the PRVB will allow a full flow through the downstream pipe work. When all the downstream taps are isolated the PRVB will control the static pressure to the valve's set pressure.

Features

  • Body made of D.R Brass
  • Superior flow capacity, 170 l/min as per AS1357.2
  • Low profile - compact design
  • Stainless steel seat
  • Metal cap for protection of the valve

Specification

Flow rating 170 l/min, as per AS1357.2
Set pressure 500kPa, at 1600kPa
Inlet Pressure Max operating temp. 80oC
Connections 20mm Female BSP to 20mm Compression
Watermark WMKA2639

GTIN: 9336629002530
