Black Diamond DIA-10D4 10" Car Subwoofer 4-Ohms DVC 440W Max

Image 1
Image 2
Image 3
Image 4
Hurry! 3 items left!
$149

Collect 149 Everyday Rewards points

Log in to MyDeal to link your card
Free Shipping

Dispatch in 2 business days

Sold & shipped by Elite Electronics
Secure ways to pay at checkout
Black Diamond 10“ Subwoofer 4-Ohm Dvc 440 Watts DIA-10D4

Features:

  • Nominal Diameter: 10″
  • Nominal Impedance: 4+4 Ohms
  • RMS Power Handling: 220W
  • MAX Power Handling: 440W
  • Sensitivity: 89.5dB
  • Frequency Response: 40Hz-4.5KHz
  • Recommended Lo Pass Crossover: 90Hz




  • Black Diamond DIA-10D4 MOTOR SPECIFICATIONS:
    • Voice Coil Diameter: 2″/50.8mm
    • Voice Coil Former Material: Aluminum
    • Winding Material: CCAW
    • Cone Material: Non-Pressed Paper
    • Dust Cap: Paper
    • Surround Material: Foam
    • Basket Material: Steel
    • Basket Color – Finish: Black
    • Magnet Material: Ferrite
    • Magnet Weight: 45 oz
    • Displacement Volume: 1.27L
  • Black Diamond DIA-10D4 TS PARAMETERS:
    • Equivalent Volume: 39.05L
    • Excursion: 13.5mm
    • Free Air Resonance: 40Hz
    • Mechanical Factor: 5.479
    • Electrical Factor: 0.831
    • Total Factor: 0.725
    • Moving Mass: 125.124g
    • Compliance: 0.046mm/N
    • Force Factor: 12.045
    • Voice Coil Inductance: 0.932mH
    • Diaphragm Area: 365.25cm2
    • Dc Resistance: 3.6+3.6 ohms
    • Efficiency Bandwidth Product: 48.13
  • Black Diamond DIA-10D4 MEASUREMENTS:
    • Overall Diameter: 10.24″/260mm
    • Overall Depth: 5.71″/145mm
    • Front Mount Baffle Cutout: 9.13″/232mm
    • Motor Diameter: 5.90″/150mm


* DISCLAIMER: Design, features and specifications subject to change without notice. Some features in videos on the Internet may not be available on all models, please contact us for the TECHNICAL SPECIFICATIONS for a complete list of features by model. This feature list is for reference only, please contact us to verify features and functionality.

GTIN: 810005188319
