Technical Specifications

• Frame: 6061 aluminium main tubes, over-sized seat tube, replaceable derailleur hanger
• Fork: XC80, coil spring, external preload adjustor, 25.4mm stanchions, aluminum lowers, 80mm travel
• Headset: VP threadless
• Wheels: Alex TD26 double wall rims, 32H, alloy 6-bolt disc hubs, 14G black electroplated spokes
• Tires: CST Patrol, 2.25
• Derailleurs: Shimano TY300 rear and TY500 front
• Shift levers: Shimano EF41, 3 7-speed
• Chain: KMC Z51, 7-speed
• Cassette: Shimano TZ31, 7-speed, 14-34T
• Crankset: Forged alloy crank, 42/34/24T, 170mm
• BB Set: Sealed cartridge
• Pedals: MTB platform, hi-impact resin
• Brakeset: Tektro M280 mechanical disc, 160mm rotors and Shimano levers
• Handlebar: XC alloy riser, 25.4 x 20mm rise x 620mm
• Stem: XC alloy threadless, 25.4 x 15 ? rise x 60mm
• Grips: Kraton
• Seat Post: Alloy micro-adjust, 31.6 x 350mm
• Saddle: ATB Sport/Sport Women's, SL cover, protective front and rear guards

Warranty

• Lifetime warranty on Frame and Fork
• 12 Months Manufacturer's Warranty on all non-consumable components
• Consumable parts (including grips, tubes, tyres, cables, brake pads, saddle coverings, chain, spokes, cassettes and chain rings) are not covered by the warranty.
