Carbon 3.0k 3000lb Utility Trailer ATV Quad Bike Electric Winch

Carbon 3.0k 3000lb Utility Trailer ATV Quad Bike Electric Winch

Be the first to review this product

SOLD OUT

Enter your email to receive a notification when this item is back in stock

The Carbon CW-3U 3.0K 3000lb winch may be a small winch, but it's one big value when you conside the reliability and the overall quality. Built to handle lighter loads ( to 3,000lb). This winch is overflowing with upgraded features, including a hand remote and wireless remote control to control power in/power-out functions and tie rods for added stability.

SPECIFICATION / PART NUMBERS CW-3U 3000lb

Part number: CW-3U

Rated line pull: 3000lbs, (1360kg) single-line

Motor: 12V DC 1.5HP Permanent Magnet motor

Remote Control: Remote Switch, 12” (3.7m) lead.

Wireless Remote Control: Included

Geartrain: Single Stage Planetary.

Gear Ratio: 153:1

Clutch (freespooling): Split Ring Gear

Brake: Self-locking gear train ( Rated Load Holding

Drum Diameter/Length: 1.26”/2.87(32mm/73mm)

Synthetic Rope: 43”, 3/16” diameter ( 13m, 4.8 diameter)

Fairlead: Roller

Mounting Bolt Pattern: 3.0” x 4.87” ( 76mm x 124mm )

Winch Dimensions ( L x W x H ): 12.2'' x 5.0'' x 5.0'' (310x 127 x 127mm )

Packing Dimensions( L x W x H ): 15.7”x 7.9'' x 8.7'' ( 400 x 200 x 220mm )

Shipping Weight: 10kg ( 22lbs)

Warranty : 1 year

12V DC PERFORMANCE SPECS (first layer of drum)
Line Pull Lbs.(Kgs.)	Line Speed FT./min(M/min.)	Motor Current	Pull by layer layer/Lbs(Kgs.)
0	20.4(6.2)	10Amps	1/3000(1360)
1000(453)	14.2(4.3)	65Amps	3/2725(1235)
2000(907)	10.9(3.3)	96Amps	3/2480(1125)
3000(1360)	7.7(2.4)

SKU: CW-3U
