Clipsal Iconic 40E1USBCM-VW | Single USB C 3.1A | 25W Fast Charging Mechanism | Vivid White

The Clipsal Iconic USB-C Charging Mechanism makes it simple to fast charge your device.
Clipsal Iconic is a modern electrical accessories range, based on a slim, sleek, clean design that is easy to customise and blends in perfectly with any environment.

Features

USB Type C
3.1A
25w fast charging
USB-C charging mechanism has been designed to eliminate bulky chargers by providing a universal charging solution whilst freeing up socket outlets.
Providing a dedicated independent port that optimises charging whilst monitoring the temperature of the device to ensure internal components don’t overheat.
This patented technology has the added advantage that enables the mechanism to be installed in harsh temperature environments.
The charging mechanism also includes a patented rotating head so that the correct orientation of the outlets can be provided in both horizontal or vertical plates.
The charger fits perfectly into the Iconic single, double or quad power outlets and can be accommodated in a deep wall box or standard mounting bracket
These energy-efficient USB Charger Mechs are compatible with both Apple® and Android™ devices and use less than 0.07W of power while in Standby mode.

Specifications:

Features:

Input Voltage: 220-240V ac 50hz
Output Voltage: 5V dc
Output Current: Max 2.1A per port (Max 3.1A for the module)
Standby Power <70mW Efficiency: >78%
Charging: BC1.2, cable compensation & Smartcharge
Operating Temperature: 0°-45° C Ambient
Operating Humidity: 5% ~ 90%
Relative Humidity, Non-Condensing Storage Temperature: 0°-60° C
Storage Humidity: 5% ~ 90% Relative Humidity, Non-Condensing
USB Connection type: 2 x USB A-Type
Input Connections 120mm flyleads, 22 AWG (0.64mm dia, 0.33mm²) terminal block supplied
IP Rating: IP20 Indoor Use Only
Rotating head angle: 180° Lifetime insertion of USB 10,000 cycles
Protection: Short circuit, Over Current and Over Temperature (self regulates output current)
Depth from rear of plate: 55mm (suits deep wall boxes)
Plate compatibility: Suitable for 40 Mech compatible wall plates (e.g. Iconic).
Not suitable for 30 series apertures.

Warranty starts from Invoice Date

Domestic Use: 2 Year
Commercial Use: 2 Year
Warranty Method: Clipsal in home warranty

GTIN: 9311554816056
