Collect 299 Everyday Rewards points
Dispatch in 2 business days
| Specifications | |
|---|---|
| Voltage | 12 - 48 VOLT |
| Function | ON / OFF |
| Number of Terminals | 4 |
| Number of Postions | 2 |
| Contact Configuration | DPST |
Features
2 Postion - On/Off, Double Pole - Single Throw, Lockable Black Actuator
500amp continuous rating per Circuit on Battery Terminals, 3,000amp Inrush rating (1 Sec)
Silver contacts, Black Plastic housing and flange
4 x 25mm, M12 x 1.75mm Thread Steel Zinc plated Battery Studs
100mm centre to centre, uses M8 or 5/16 Bolts
Housing Protection Rating: IP67 and IP69K, 30G Shock, 8G Vibration Resistance
| Specifications | |
|---|---|
| Voltage | 12 - 48 VOLT |
| Function | ON / OFF |
| Number of Terminals | 4 |
| Number of Postions | 2 |
| Contact Configuration | DPST |
Features
2 Postion - On/Off, Double Pole - Single Throw, Lockable Black Actuator
500amp continuous rating per Circuit on Battery Terminals, 3,000amp Inrush rating (1 Sec)
Silver contacts, Black Plastic housing and flange
4 x 25mm, M12 x 1.75mm Thread Steel Zinc plated Battery Studs
100mm centre to centre, uses M8 or 5/16 Bolts
Housing Protection Rating: IP67 and IP69K, 30G Shock, 8G Vibration Resistance
Cole Hersee Battery Master Switches
Heavy Duty
4 Pole IP69K Rating
500amp continuous rating per Circuit on Battery Terminals, 3,000amp Inrush rating (1 Sec)
MPN: SW8801
Estimated Delivery Time Frame:5-10 business days
Ask a Question About This Product
Reference ID: 10305784
