Crestron AMP-1200-100 Single-Channel Modular Power Amplifier 200W 100V

Image 1
Image 2
$120

Sold Out

Notify me when this product is back in stock

To understand how we handle your personal information, see our Privacy Collection Notice and Privacy Policy.

Shop More Products
Sold & shipped by Australian Computer Traders

Provides a professional amplifier solution for commercial applications that saves energy, space, and money. Unique modular design is super easy to configure and ships with everything required to enable surface mounting, rack mounting, and ganging multiple units together.

Key Features
  • ENERGY STAR® certified power amplifier
  • Ultra-efficient space-saving design
  • Choice of 70V or 100V output
  • Single channel, 200 Watts
  • Half-width, 1 RU form factor
  • Surface or rack mountable
  • Gangable with other Crestron® modular amps
  • All mounting and ganging hardware included
  • High-density stackable
  • Convection cooling — no mechanical fans
  • Comprehensive fault and speaker protection
  • Clip limiter
  • Low noise, low distortion, high headroom
  • Low power consumption
  • Automatic low-power standby
  • Balanced and unbalanced inputs
  • Detachable terminal blocks for easy servicing
  • Front panel level adjustment with tamper-preventive magnetic cover
  • Front panel power/standby, fault, and signal/clip indicators
  • Internal universal 100-240V power supply
Audio
  Input Signal Types Balanced or unbalanced analog line-level
  Output Power,
AMP-1200-70		 200 Watts @ 70 Volts nominal
  Output Power,
AMP-1200-100		 200 Watts @ 100 Volts nominal
  Frequency Response 200 Hz to 20 kHz ±0.5 dB
  High-Pass Filter -3 dB @ 80 Hz, 12 dB per octave
  THD+N <0.1% [1]
  S/N Ratio >100 dBA, 20 Hz to 20 kHz, balanced
  Input Sensitivity 1.23 Vrms, +4 dBu, balanced;
0.316 Vrms, -10 dBV, unbalanced;
For full rated output power
  Go To Sleep Time 25 minutes with no signal present
  Wake Time 0.5 second typical
  Wake Threshold 5 to 20 mV typical
  Protection Clip limiter, over current, under voltage, over temperature, DC offset, extreme high frequency
Connectors
  SPEAKER OUT (1) 2-pin 7.62 mm reversed gender 20A detachable terminal block;
Power amplifier output;
Wire Size: Terminals accept up to 12 AWG (3.31 mm²);
Note: Output is direct-coupled, not transformer isolated
  AUDIO IN L/R
(unbalanced)		 (2) RCA connectors, female;
Unbalanced line-level audio inputs (summed);
Maximum Input Level: 2.24 Vrms, +7 dBV (+9.2 dBu)
  AUDIO IN L/R
(balanced)		 (1) 5-pin 3.5 mm detachable terminal block;
Balanced line-level audio inputs (summed);
Maximum Input Level: 7.75 Vrms, +20 dBu;
Input Impedance: 20k Ohms
  G (1) 6-32 screw;
Chassis ground lug
  100-240V~1A 50/60 Hz (1) IEC 60320 C14 main power inlet;
Mates with removable power cord, included
Controls & Indicators
  PWR (1) Bi-color green/amber LED, indicates operating power supplied from AC line power, turns green while operating and amber when in standby
  FAULT (1) Red LED; indicates an over-temperature or over-current fault
  SIGNAL (1) Bi-color green/red LED, green indicates input signal presence and red indicates input signal clipping
  Input Level (1) Screwdriver-adjustable rotary control, adjusts the input attenuation level, tamper-preventive magnetic cover included
Power
  Main Power 1 Amp @ 100-240 Volts AC, 50/60 Hz
  Power Consumption 45 Watts, driven at 1/8th output power;
16 Watts, idle;
<0.5 Watt, standby (sleep)
Environmental
  Temperature 41° to 104°F (5° to 40°C)
  Humidity 10% to 90% RH (non-condensing)
Construction
  Chassis Metal, convection-cooled (fanless), vented front and rear
  Front Panel Metal, black finish with polycarbonate label overlay
  Mounting Freestanding, surface-mount, or 1/2-width 1 RU 19-inch rack-mountable; gangable with other Crestron modular AMP series products (adhesive feet, surface mounting kit, ganging kit, and rack mounting kit included)
Dimensions
  Height 1.74 in (45 cm) without feet;
1.82 in (47 mm) with surface kit
  Width 8.65 in (220 mm);
9.75 in (248 mm) with surface kit;
19.00 in (483 mm) with rack kit
  Depth 10.46 in (266 mm)
Weight
  4.2 lb (1.9 kg) without mounting kits;
4.5 lb (2.0 kg) maximum with surface or rack kit
Compliance
  ENERGY STAR, ErP (1275/2008/EC), UL 60065, FCC Class A commercial use

Specifications:

Audio
  Input Signal Types Balanced or unbalanced analog line-level
  Output Power,
AMP-1200-70		 200 Watts @ 70 Volts nominal
  Output Power,
AMP-1200-100		 200 Watts @ 100 Volts nominal
  Frequency Response 200 Hz to 20 kHz ±0.5 dB
  High-Pass Filter -3 dB @ 80 Hz, 12 dB per octave
  THD+N <0.1% [1]
  S/N Ratio >100 dBA, 20 Hz to 20 kHz, balanced
  Input Sensitivity 1.23 Vrms, +4 dBu, balanced;
0.316 Vrms, -10 dBV, unbalanced;
For full rated output power
  Go To Sleep Time 25 minutes with no signal present
  Wake Time 0.5 second typical
  Wake Threshold 5 to 20 mV typical
  Protection Clip limiter, over current, under voltage, over temperature, DC offset, extreme high frequency
Connectors
  SPEAKER OUT (1) 2-pin 7.62 mm reversed gender 20A detachable terminal block;
Power amplifier output;
Wire Size: Terminals accept up to 12 AWG (3.31 mm²);
Note: Output is direct-coupled, not transformer isolated
  AUDIO IN L/R
(unbalanced)		 (2) RCA connectors, female;
Unbalanced line-level audio inputs (summed);
Maximum Input Level: 2.24 Vrms, +7 dBV (+9.2 dBu)
  AUDIO IN L/R
(balanced)		 (1) 5-pin 3.5 mm detachable terminal block;
Balanced line-level audio inputs (summed);
Maximum Input Level: 7.75 Vrms, +20 dBu;
Input Impedance: 20k Ohms
  G (1) 6-32 screw;
Chassis ground lug
  100-240V~1A 50/60 Hz (1) IEC 60320 C14 main power inlet;
Mates with removable power cord, included
Controls & Indicators
  PWR (1) Bi-color green/amber LED, indicates operating power supplied from AC line power, turns green while operating and amber when in standby
  FAULT (1) Red LED; indicates an over-temperature or over-current fault
  SIGNAL (1) Bi-color green/red LED, green indicates input signal presence and red indicates input signal clipping
  Input Level (1) Screwdriver-adjustable rotary control, adjusts the input attenuation level, tamper-preventive magnetic cover included
Power
  Main Power 1 Amp @ 100-240 Volts AC, 50/60 Hz
  Power Consumption 45 Watts, driven at 1/8th output power;
16 Watts, idle;
<0.5 Watt, standby (sleep)
Environmental
  Temperature 41° to 104°F (5° to 40°C)
  Humidity 10% to 90% RH (non-condensing)
Construction
  Chassis Metal, convection-cooled (fanless), vented front and rear
  Front Panel Metal, black finish with polycarbonate label overlay
  Mounting Freestanding, surface-mount, or 1/2-width 1 RU 19-inch rack-mountable; gangable with other Crestron modular AMP series products (adhesive feet, surface mounting kit, ganging kit, and rack mounting kit included)
Dimensions
  Height 1.74 in (45 cm) without feet;
1.82 in (47 mm) with surface kit
  Width 8.65 in (220 mm);
9.75 in (248 mm) with surface kit;
19.00 in (483 mm) with rack kit
  Depth 10.46 in (266 mm)
Weight
  4.2 lb (1.9 kg) without mounting kits;
4.5 lb (2.0 kg) maximum with surface or rack kit
Compliance
  ENERGY STAR, ErP (1275/2008/EC), UL 60065, FCC Class A commercial use
