DiaMec 19.5A 12V 1.3Ah Spade Terminals Connection Rechargeable Sealed Lead Acid Battery

Features

• Charge current 130mA for 10-14 hours
• Discharge current 20 hour rate 65mA
• Int Resistance: Fully charged (20°C,68°F) 110mOhm
• Max Discharge Current (5 sec):40A
• Constant Voltage Charge: Initial charging current < 0.39A
• Voltage 14.4V~15.0V @ 20°C (68°F)
• Temp Coefficient: - 30mV/°C
• Voltage 13.5V~13.8V @ 20°C (68°F)
• Temp Coefficient: - 20mV/°C

Specifications

• DC Voltage : 12.00000000V
• Length : 97.00000000mm
• Height : 57.00000000mm
• Depth : 43.00000000mm
• DG UN Number : 2800.00000000
• DG Ship Name : 2800 - Batteries, wet, non-spillable, electric storage
• DG Class : 8.00000000
• DG Pack Group : III - Minor Danger
• Battery Watt Hour Rating (Required for Lithium Batteries) : 15.60000000Wh
• Dangerous Road Freight : true
• Dangerous Air Freight : true
• Standard Recharge Current : 130.00000000A
• Battery quantity : 1.00000000pc
• Recharging Time : 20.00000000hr
• Battery Chemical Composition : Sealed Lead Acid (SLA)
• Battery usage : Rechargeable
• Amp Hour Rating : 1.30000000Ah
• 20 Hour Capacity : 1.30000000Ah
• 10 Hour Capacity : 1.20000000Ah
• 5 Hour Capacity : 1.10000000Ah
• 1 Hour Capacity : 0.73000000Ah
• Internal Resistance : 110.00000000m
• Connection Type : Spade Terminals
