The VMAX® IP Plus™ is an easy to use PoE NVR that allows you to go from power up to monitoring in less than three minutes! Combine with the DW Witness™ app to turn the camera on a smartphone or tablet into a surveillance camera that can be viewed and recorded on the NVR.
Available with 8 PoE ports (expandable to 12 cameras), the NVRs can record and manage single-sensor IP cameras up to 4K, with 80Mbps maximum throughput.

Digital Watchdog® IP cameras, analog cameras, NVRs, DVRs, network devices and management software sold and distributed worldwide are designed and developed in U.S.A. and Korea.Manufactured in South Korea and Taiwan.

• Complete installation, set up and camera configuration in under three minutes!

• CCIP™ system encryption protects your surveillance system from out of network attacks

• Record and manage single-sensor IP cameras up to 4K (3840×2160), with 80Mbps maximum throughput

• Local power for up to 8 IP cameras via resident PoE switch

• DW Witness™ turns a smartphone or tablet into an additional surveillance camera

• PathFinder™ Peer-to-Peer (P2P) remote connection

• HTTPS encryption supported

• Automatic device discovery

• Control any ONVIF camera's set up and features remotely

• 0TB-32TB storage options

• Snapshot Notify™: camera notifications sent to an email or CMS

• C3™ CMS and event server software up to 144 Channels

• Event notifications via email, text and C3™ CMS and push notifications to mobile devices

• Mobile application for iPhone, iPad, iPod, Android smartphones and tablets and Apple TV

• Dual-stream recording

• Easy drag and drop camera management

• Instant backup during playback

• Full HD output for local live and playback display up to 4K (3840×2160)

• Complete system analysis with real-time system, network and PoE status monitoring

• True HD and VGA simultaneous output support

• 4 sensor input, 1 alarm relay output

• Transaction verification via TCP and USB-serial

• Email event notifications with video clip

• Simple and free DDNS support for remote management

• Easy web-based client with multi-user access

• Advanced H.265, H.264 Linux embedded NVR

• Simultaneous live, playback, recording, back-up and network

• NVR health check with email notification

• NVR calculation and auto-recording configuration

• Help menu on major functions

• Add public view monitors with Spot Monitoring Modules

• Auto or manual firmware upgrade available

• Automatic private IP addressing

• NTP (network time protocol)

• Screen saver to protect monitor screen

• Import/export configuration between multiple NVRs

• USB mouse and GUI control

• 3 year warranty


•

  Aussie Stock
  All our stock is kept in our Melbourne based warehouse. Our stock levels are also updated every 10 minutes! So if it says 10 units in stock, you can trust that it is accurate.

  No PO Boxes or Parcel Lockers
  At this stage we only use couriers and can only deliver to a road-side address. This means PO Boxes and Parcel Lockers cannot be accepted as StarTrack do not deliver to these addresses.
  In instances where a PO Box or Parcel Locker address in entered, we may ask for an alternative road-side address, or cancel and refund your order immediately and urge you to replace your order with an alternative delivery address.

  Delivery times
  We typically dispatch our goods same day or next day. From there, you can expect 2 - 8 business days Australia wide. Most capital cities can expect 1-2 day delivery times.
  Any RTS (Return to Sender) orders due to missing or incorrect address information entered by the buyer may incur an additional charge for redelivery.

  Operating system	Embedded Linux®
  System	Video compression	H.265, H.264
  Channel	12 Channel (DW-PVX16W multi-sensor IP camera uses 4 channels in the recorder, one per sensor).
  No. of PoE	8 Ch
  Max supported resolution	IP camera max. 4K (3840×2160)
  Communication protocol	ONVIF®
  PoE type	1Gbps, 802.3af
  Display	Speed	360fps
  Screen mode	1, 4, 9 and 12
  Video-out	Monitor	True HD and VGA
  resolution	1024x768, 1280x720, 1280x1024, 1920x1080, 2560x1600, 3840×2160 (4K)
  Recording speed	Up to 360fps up to 4K resolution
  Max. throughput	80 Mbps
  Max. HDD bay	4 x SATA HDD, up to 32TB
  Recording resolution	Dual-stream
  Recording modes	Continuous, C+M, C+S, scheduled, sensor and motion detection recording
  Pre-alarm recording, emergency recording, quick backup
  Playback and search	Speed	x1, x2, x4, x8, x16, x32, x64, x100
  Function	Intelli-search by time bar, calendar (date and time) and event search
  Audio output	1 Ch
  Alarm input/relay output	4 Ch/ 1 Ch
  PTZ control	RS-485, ONVIF
  Transaction verification	TCP and USB-serial interface
  LAN	1x gigabit ethernet (RJ45) - fixed IP, DHCP and DDNS
  Access	Web viewer: Live, playback and configuration up to 10 multiple connections
  Client monitoring software:Mac® (Apple® S/W), C3™ (CMS S/W)
  Compatible mobile apps:
  Backup device	Local backup by USB, network backup by CMS
  System recovery after power failure	Auto-reboot and journaling file system
  Other function	Firmware upgrade	FTP, USB
  Back-up	Remote, USB
  Special features	Local PoE switch Quick Setup under 3 minutes Snapshot Notify™: Programmable interval camera image verification sent to an email Event notifications via email, text and C3™ CMS and push notifications to mobile devices Real-time temp alert Digital Zoom in live and playback
  Health check	Real-time system, network and PoE status monitoring
  System operation	IR remote controller (optional), USB mouse, PTZ control by keyboard (optional)
  Power requirements	110~240V A/C
  Total PoE Power Budget	150W
  Max. Power per Port	30W
  Power consumption	360 W total power budget, 5.5A, 18.75W per PoE channel (simultaneous)
  Operating temperature and humidity	41~104 °F (5~40 °C) / 20~90% RH
