DrayTek DAP960C - 2x2 Dual Band 802.11ax Ceiling AP with Mesh Wi-Fi, 1 x Gigabit PoE PD port, and support VigorACS 2/3

DrayTek DAP960C - 2x2 Dual Band 802.11ax Ceiling AP with Mesh Wi-Fi, 1 x Gigabit PoE PD port, and support VigorACS 2/3

Be the first to review this product

Hurry! 8 items left!

Price	$337.52
	Earn 3x points and collect 1011 Everyday Rewards points. Promotion ends 16/05/2024. Create a MyDeal Account or Login to link your card
Shipping	Unable to calculate delivery for , please Contact Us Delivery unavailable to Change
	24-48 hour dispatch See delivery details

Quantity

Add to wishlist

VigorAP 960C 2x2 Dual Band 802.11ax Ceiling AP

VigorAP 960C is an 11ax ceiling-mount wireless access point. With wire-liked speed up to 1.2 Gbps in 5GHz band and 600Mbps in 2.4GHz, it’s suitable for high density environments. It can be cloud-managed by VigorACS, and also act as the mesh Root AP to manage up to 7 mesh node APs in LAN.

Utilize Transmission Opportunity with OFDMAOFDMA has been used in LTE for many years, and is now available in 802.11ax for multi-user mode.

Traditionally with OFDM, each frame is transmitted across the entire channel width. With low-rate transmission still using the whole channel, it brings latency and jitter to others and lower the overall efficiency.

OFDMA splits a single transmission into groups of subcarriers, and each subcarrier can be used by different client. With multiple clients transmitting simultaneously in the same channel, it improves efficiency of every single transmission opportunity and thus increases the wireless experiences in high density environment.

AP-assisted Roaming

Making Transmission Effective: Disassociate the Wireless clients who are out of the effective transmission range defined by custom Basic Rate or/and RSSI threshold, and force them to pick up another access point with a stronger signal.

Resource Saving:Proactively kick out the clients with a low basic rate or low RSSI can prevent the access points trying to do ineffective transmission but saving the airtime, which will results in better WLAN experience for all.

No Controller Required:Assisted Roaming is a feature built in all Vigor Access Points and selected Wireless routers. They operate without a wireless controller, providing an ideal solution for simple network deployment.

Stronger Signal Guaranteed:By using the "Minimum RSSI with Adjacent AP" option, the AP/Router on the same local subnet will exchange client information with each other, providing the choice to disassociate the client only when other AP detecting a stronger signal. Thus to keep the client stayed when there is no other AP nearby.

What’s in it for you?

Mesh (Wireless model only):Easily link to other VigorAP to expand the wireless network.

PoE Power Supply:Simplify the infrastructure by getting data and power through a single cable.

Multiple SSID:Mapping Wi-Fi clients to different VLANs and have a different set of security standards.

Airtime Fairness:Equalize the transmission time of each client so the legacy devices won't slow everyone down.

Band Steering:Redirect 5GHz-capable devices to the 5GHz radio to get a faster speed.

Assisted Wi-Fi Roaming:Solve the sticky client problem and improve Wi-Fi roaming experience.

Wi-Fi Scheduling:Schedule Wi-Fi On and Off to control wireless access and save energy.

Local RADIUS Server:User profile database for local and external 802.1x authentication.

Hotspot Web Portal:Market your business and communicate with the guests while offering hospitality WLAN.

Central AP Management:Manage, maintain, and monitor VigorAP 960C from the DrayTek routers.

Specifications:

Interface
LAN Port	1x 10/100/1000M Base-T, RJ-45 (PoE-PD Support)
Antenna	2x Internal PiFA Dual-Band Gain: 3 dBi for 5GHz, 1.3 dBi for 2.4GHz
Button	1x Factory Reset Button
DC Power Jack	1
Security Lock	1
Capacity
2.4GHz Peak Speed	600 Mbps
5GHz Peak Speed	1200 Mbps
Max. Number of Concurrent Active Clients	256 (128 per radio band)
WLAN
2.4GHz Standard	IEEE 802.11b/g/n/ax 2x2 MIMO
5GHz Standard	IEEE 802.11a/n/ac Wave 2/ax 2x2 MU-MIMO
Operating Mode	AP, Mesh Root, Mesh Node, Range Extender
Roaming	AP-Assisted Roaming, PMK-Caching, Pre-Authentication, 802.11r
AirTime Fairness	✔
Band Steering	✔
Auto Channel Selection	✔
Max. Number of SSID	8 (4 per radio band)
WDS	✔
Client Numer Limit	Per radio, Per SSID
Connection Time Control	✔
WMM	✔
IGMP Snooping	✔
Security
Security Mode	WPA3, WPA3/WPA2, WPA2, WPA2/WPA, OWE, WPA, WEP, None
Authentication	Personal, Enterprise
WPS	PIN, PBC
Hidden SSIDs	✔
MAC Address Filter	Up to 256 entries
Wireless Client Isolation	✔
Mobile Device Management	✔
Application
Built-in RADIUS Server	✔
RADIUS Proxy	PEAP, EAP-TLS
Hotspot Web Portal	✔
DHCP	DHCP Server, DHCP, Client, DHCP Relay Agent
Static IP	✔
MAC Clone	✔
802.1q VLAN	✔
Schedule	Auto-Reboot, Wi-Fi Up/Down, LED On/Off
Management
Local Service	HTTP, HTTPS, Telnet
Configuration	Stand Alone, TR-069 (VigorACS), VigorRouter APM, VigorAP Mesh Root
Firmware Upgrade	HTTP, TFTP, TR-069
Tools	Speed Test, AP Discovery, Statistics, Interference Monitor
Configuration Backup and Restore	✔
Syslog	✔
Mail Alert	✔
SNMP	v1, v2c, v3
Managed by VigorConnect	✔
Managed by VigorACS	✔
Central AP Management	30 VigorAP
Physical
Environment	Indoor
Mounting	Ceiling Mount, Wall Mount
Power Method	DC 12V @ 1A / 802.3af PoE
Max. Power Consumption	11 watts
Dimension	178 mm x 178 mm x 35 mm
Weight	380 g
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Operating Humidity	10 to 90% non-condensing
Certificate
