Dynamix FP-C6S-011 Cat6 Shielded Keystone Jack Termination 110/Krone [FP-C6S-011]

Image 1
Image 2
Image 3
Image 4
Hurry! 15 items left!
$19.48

Collect 19 Everyday Rewards points

Log in to MyDeal to link your card
Sold & shipped by F Digital Direct Import
Secure ways to pay at checkout
Dynamix FP-C6S-011 Cat6 Shielded Keystone Jack Termination 110/Krone

DYNAMIX Cat6 Shielded Keystone Jack Termination 110/Krone
Our DYNAMIX 90° Cat6 Keystone Jack has a fully shielded design to protect from EMI. Dual IDC connectors can accept 22-26 AWG solid cables and supports T568 A&B wiring, plus it uses 110 or Krone tools for termination.
FP-C6S-011 is made to an extremely high standard and superior construction ensures that our Cat6 shielded Keystone Jack conform to ANSI/TIA-568-C.2, ISO/IEC 11801 and EN50173-1 Category 6 specifications, and supports channel link bandwidth up to 250MHz.
FEATURES
- Shielded Cat6 keystone jack
- RJ45 Female connector
- 90° Angle termination design
- Supports gauge wire 22-26AWG cable
- Compatible with shielded or unshielded patch cables
- Use with a wall-plate for network wiring installs
- Designed for high-speed network applications
- Excellent crosstalk suppression
- Corrosion-resistant construction
- Operating temperature -10°C to 60°C (-14°F to 140°F)
- Category 6 ANSI/TIA/EIA 568-C.2 performance

Shielded Shell
Brass, Nickel plated
Jack Terminal
Phosphor Bronze, 3U gold plated over Nickel plated in contact area
IDC Housing
ABS Plastic
IDC Terminal
Phosphor Bronze, nickel plated 50~60, micro inch
P.C. Board
FR-4, T=1.6mm
Operating Temperature
-10°C~60°C
Insertion Force
900gms for 8 Contacts
Retention
7.7kgs between jack and plug
Durability
750 Cycles contact resistance test check with 10mm/s
Supports
T568A & T568B wiring compatible with Cat6 requirements
Tool
Dual Type
Current Rating
1.5 Amps
Insulation Resistance
500MO
Contact Resistance
20MO
DC Resistance
0.1O
Rated Voltage
500V
- MPN: FP-C6S-011

GTIN: 3969322121541
