Feiyu AK4500 3-Axis Handheld Gimbal Stabilizer

Feiyu AK4500 3-Axis Handheld Gimbal Stabilizer

Be the first to review this product

SOLD OUT

Enter your email to receive a notification when this item is back in stock

Feiyu AK4500 3-Axis Handheld Gimbal Stabilizer

The Feiyu AK4500 3-Axis Handheld Gimbal Stabilizer is a compact 3-axis gimbal stabilizer that improves on its predecessor, the AK4000, by supporting up to 10.1 lb loads. It's designed with an angled motor arm so there's nothing blocking your camera screen, and it provides 360° pan, 230° tilt, and 360° roll motion. The touchscreen LCD, the joystick, and the handwheel work together to let you assign and adjust all the settings of the gimbal. The gimbal also includes the companion Feiyu ON iOS/Android app (free download) that lets you adjust settings and perform various actions remotely. The Hyperlink remote controller is also included so you can perform all the above gimbal control actions up to 49' away from the gimbal via Bluetooth.

The gimbal features a multifunction handwheel on the side and a touchscreen LCD smart panel integrated into the handle. The handwheel allows you to control the movement of the camera in select operational modes, including pan and tilt modes and also lets you digitally control focus and zoom with compatible cameras. Additionally, an external focus motor is included and the handwheel is capable of controlling it as well. Please visit the Feiyu website for a list of compatible cameras for standard operation as well as Wi-Fi focus/zoom control.

The roll and tilt direction are fixed and the camera moves left/right, according to the movements of the user's hand

One of the selectable modes of operation is an autorotation mode that allows you to assign a pre-set travel route for standard video capture as well as time-lapse photography

Four included 18650 lithium-polymer batteries (2200mAh each) install into the handle to provide up to 12 hours of battery life

Specifications:

Number of Axes:	3-Axis (Pitch, Roll, Yaw)
Rotation Range:	Yaw (Pan): 360° Pitch (Tilt): 230° (-55 to 175°) Roll: 360°
Follow Speed:	Tilt: 2 to 75°/s Pan: 3 to 150°/s
Load Capacity:	10.14 lb / 4.6 kg

Wireless Protocol:

Bluetooth (Unspecified Type), Wi-Fi (Unspecified Type)

Battery Type:	4 x 18650
Capacity (mAh):	2200 mAh
Battery Runtime:	12 Hours
Battery Chemistry:	Lithium-Ion Polymer (LiPo)
Voltage:	3.7 VDC

Materials:	Aluminum
Mounting:	5 x 1/4"-20 Female
Dimensions:	16.89 x 9.45 x 6.9" / 42.9 x 24 x 17.53 cm
Weight:	3.64 lb / 1656 g (without Battery)

Expected Battery Life:	18 Hours
Weight:	9.56 oz / 271 g

GTIN: 6970078071742
