A powerful 2840-2850Kv outrunner motor and 12-Blade EDF unit
40 Amp ESC with thrust reversing capability
Full size, independent elevators provide level flight and improved aircraft climbing ability
Main wing, rudder and elevators are all detachable making the aircraft easy to transport and easy to repair (no gluing)
Fixed, scale landing gear design helps keep the F-22 lightweight and also improves the model's flying life
Large ESC cooling vents help extend the life of the on-board electronics
Nylon hinges on all control surfaces (superior to foam hinges)
Durable EPO material is stronger and more flexible than conventional foam airframes
Brushless motor, ESC and servos come pre-installed for your convenience
Requires:
4 Channel radio - select a minimum 4 channel radio from our Radio Collection
4 Channel receiver - select a minimum 4 channel receiver from our Receiver Collection
4 Cell 14.8V 2200 mAh LiPo Battery with XT60 Connector
4 Cell compatible battery charger - select a minimum 4 cell (4S) charger from our Charger Collection

Wingspan 690mm / 27.2in
Length 950mm / 37.4in
Flying Weight 850g / 29.98oz
Power System 2840-2850Kv brushless outrunner motor
Speed Control 40A, internal SBEC with XT60 Connector
Propeller / EDF 64mm 12-Blade EDF
Servos
9g plastic standard with 100mm lead : left elevator, left aileron, right aileron
9g plastic reverse with 100mm lead : right elevator
9g plastic standard with 300mm lead : nose gear steering
Landing Gear Fixed main landing gear, steerable nose gear
Required Battery 4S 14.8V 1600mAh to 2200Ah 30C LiPo
Required Radio 4 Channel 2.4ghz radio
Rudder No
Flaps No
Ailerons Yes
Lights No
Hinge Type Nylon hinges on all control surfaces
Material EPO Foam
Skill Level Intermediate
Build Time 1 Hour
Recommended Environment Outdoors
