GANNET X DRONE FISHING BAIT RELEASE FOR DJI PHANTOM 3 & 4 GANNET

*Colours May Vary* due to manufacturing changes some of the models have been canged to a dark grey colour

Main features:

1. Fits all Phantom 3’s & 4’s
2. Designed not to interfere with your drones VPS sensors. All remain ON, unobstructed and active, no need to move it to the back legs to clear the sensors.
3. Mounts in seconds to your drone with no tools required, no removal of the LEDs lens,
4. Clear from the drone camera including the large P4Pro & Adv camera.
5. Over 10kg release ability - A Phantom can lift 1.4kg Max, 800g Max recommended bait, more possible but not recommended.
6. Selectable auto mechanical release or full lock - for the guys that fly amongst the gulls, adding protection against reel jams with emergency bail.
7. Is fully autonomous and self-sufficient with its own rechargeable battery, charged from an internal charger powred by USB charge lead in under 30min. Single charge can do over 100 drops, Over 2 week stand by if left on (warning this could dammage the battery)
8. No need to modify your drone in any manner nor do you need to open it,
9. Central loading same as all other Gannets - balancing the load on all 4 motors, this is fundimental to all drones. See WARNING section below for more details.
10. All electronics are kept away from the light-bridge antennas and compasses that are located in all 4 the drones legs. Thus ensuring interference-free operation of your drone even at long distances,
11. Is activated by the front LED lights of your drone which can easily be turned on and off using your C1 or C2 buttons on your drone's remote * . Alternatively, you can set your drones camera that when you start recording that it automatically switches the lights off, stop the record and the lights are back on.
12. Fastest one hand loading of all releases, even while the drone is hovering. With no need for metal/plastic rings on the Drop-Loop. Designed for 0,25mm to 1,2mm nylon Drop-Loops.
13. Instant activation from the C1 or C2 button on the drone remote, - full distance range of the drone.
14. All 4 flight LED lights remain fully functional and visible (No LED is blocked off), Gannet X can be used in Light or Dark mode (user selectable)
15. Smallest, most compact and most powerful Gannet to date and the smallest release in the market by a very large margin. Weighing in at only 55g. Weight saved on the release is safety gained for the flight reducing drone power consumption.
16. High quality injection moulded body with brass release pin. Design and appearance matching that of DJI themselves.

* excludes Phantom 3 Standard that does not have C1/2 buttons and needs activation from within the DJI Go App

WARNINGS & CONCERNS REGARDING OTHER DESIGNS

1. DO NOT disable VPS or Landing Protection, critical systems that protect your drone, camera & gimbal as well as personal and public safety. Other designs that require VPS to be disabled are compromised and should be avoided. For more on VPS and flying over water please see https://youtu.be/FihnvkaN83M
2. Some designs require yanking the line free, the drone IMU does not handle repeated sudden movements well, nor is it good for the drone legs that house the radio antennas and compasses.
3. Some designs force off center loading, to any side, especially the back in order to clear the VPS sensors, this reduces the load carrying ability by up to 40% if central back and up to 60% if off center to back, this dramatically increases drone instability, as individual motors overspeed while countering the imbalance resulting in loss of control. These designs that require off center loading are compromised and should be avoided as having one or two motors over work and fail over water is fatal. These designs make several claims to try justify loading off center, these claims are false and designed merely to justify a poor concept.
4. There are designs that lift “near” the center but when they do they interfere with the VPS, these designs have options to clear the sensors but in those positions they then lift the load totally wrong.
5. Several designs weigh over 100g, any unnecessary weight added to the release is unnecessary power sapping on the drone, also reducing the max bait load by the equivalent. Every 50g saps approximately 5% more power from the battery 100% of the time the drone is airborne. So in 4 bait drops the drone has lost near 1:30min flight time just because of the heavy release. This can be the difference of making it back to shore or having the drone go for a swim.
6. When using a downrigger clip: The addition of the downrigger clip requires VPS to be disabled - Gannet takes no responsibility for any losses that may be sustained as a result of disabling VPS. Gannet also do not recommend using this methord (downrigger clip) for every day use, yanking the line free, puts unnecessary stress and shock on the drone legs, which houses the radio antennas and compasses and may also negativly affect the drone’s very sensitive IMU.

What's in the box?

1. Gannet X with Phantom 3 sensor.
2. Phantom 4 sensor adaptor in optional Selection
3. USB Charge lead.
4. 2 of body securing bands.
5. Instruction leaflet.
