Grundfos TP 4- Pole Fixed Speed Inline Pumps

Image 1
Image 2
Image 3
Image 4
Image 5
From$4280

Collect 4280 Everyday Rewards points

Log in to MyDeal to link your card
$15.00 Australia-wide (per-item)
Sold & shipped by Sprinklerpros
Secure ways to pay at checkout

Grundfos TP pumps are single-stage, close-coupled in-line centrifugal pumps with mechanical shaft seal and primely for applications such as heating/cooling/district energy. The pumps are fitted with fixed speed motors.



Specification:

Ambient temperature : 0°C to +40°C
Liquid temperature : Clean water / Glycol: -25°C to +120°C
Shaft seal : Clean water / Glycol: BQQE (Rubber bellows seal / Silicon carbide / Silicon carbide / EPDM) - Others on request.
Supply voltage : 1 x 230 Volt 50 Hz
3 x 220-240 Volt D/380-415 Volt Y up to 2.2 kW
from 3.0 up to 5.5 kW: 3 x 380-415 Volt D 50 Hz
from 7.5 kW: 3 x 380-415 Volt D/660-690 Volt Y 50 Hz
Efficiency Class : IE3
Enclosure Class : IP55
Material : Cast iron housing / Impeller Stainless steel AISI 304 or Bronze
Base Plate : Pumps with 11 kW motors and above have base fitted as standard. Base plates for smaller pumps are available. Refer to Page 4.25
Warranty : 2 Years

Connection Port-to-port length [mm] P2 [kW] In [A] PN [bar]
3~
DN 40 440 0.75 3.1-2.9/1.79-1.66 16
1.10 4.41-3.99/2.52-2.28 16
DN 50 440 1.50 5.78-5.23/3.31-2.99 16
2.20 8.01-7.32/4.67-4.23 16
3.00 10.82-9.79/6.3-5.7 16
DN 65 475 1.50 6.2-5.6/3.6-3.2 16
2.20 8.01-7.32/4.67-4.23  16
3.00 10.82-9.79/6.3-5.7 16
4.00 8.3-7.51/4.83-4.37 16
DN 80 440 2.20 4.67-4.23/2.68-2.42  16
500 3.00 10.82-9.79/6.3-5.7 16
4.00 8.3-7.51/4.83-4.37 16
620 5.50 11.13-10.1/6.4-5.8 16
7.50 15.12-13.7/8.72-7.89 16
11.00 21.53-19.5/12.4-11.2 16
DN 100 550 1.50 5.78-5.23/3.31-2.99 16
2.20 8.01-7.32/4.67-4.23 16
3.00 10.82-9.79/6.3-5.7 16
4.00 8.3-7.51/4.83-4.37 16
5.50 11.13-10.1/6.4-5.8 16
670 7.50 15.12-13.7/8.72-7.89 16
11.00 21.53-19.5/12.4-11.2 16
15.00 29.93-27.1/17.4-15.8 16
18.50 37.0-33.5/21.6-19.6 16



Estimated Delivery Time Frame:7-14 business days
