Grundfos UPS25-60-N-180 Hot Water Circulator Pump 240V 60 Watt 25MM (96913085)

Grundfos UPS25-60-N-180 Hot Water Circulator Pump 240V 60 Watt 25MM (96913085)

Hurry! 10 items left!

$789

Collect 789 Everyday Rewards points

$75.00 Australia-wide (per-item)

Sold & shipped by Sprinklerpros

Secure ways to pay at checkout

(0)

Description

Grundfos UP, UPS N circulator pumps have a corrosion-free stainless-steel pump housing and are recommended for domestic hot-water recirculation and underfloor heating systems. UP, UPS N can be connected to an on/off time switch to limit pump operation to periods when hot water is usually required.

Specifications

Speed no	3
Head max	60 dm
TF class	110
Approvals on nameplate	CE,EAC,WEEE,RCM
Materials
Pump housing	Stainless steel
	DIN W.-Nr. 1.4301
Impeller	Composite, PES/PP
Installation
Amb. max at 80 dgr C liquid	40 °C
Maximum operating pressure	10 bar
Pipe connection	G 1 1/2
Pressure rating	PN 10
Port-to-port length	180 mm
Liquid
Pumped liquid	Water
Liquid temperature range	2 .. 110 °C
Selected liquid temperature	60 °C
Density	983.2 kg/m³
Electrical data
Power input in speed 1	50 W
Power input in speed 2	55 W
Max. power input	60 W
Mains frequency	50 Hz
Rated voltage	1 x 230 V
Current in speed 1	0.21 A
Current in speed 2	0.25 A
Current in speed 3	0.28 A
Capacitor size - run	2.5 µF
Enclosure class (IEC 34-5)	IP44
Insulation class (IEC 85)	H
Built-in motor protection	NONE
Thermal protec	Impedance protected
Controls
Pos term box	9H
Others
Net weight	2.9 kg
Gross weight	3.1 kg
Shipping volume	0.004 m³
Country of origin	RS
Custom tariff no.	8413709062
