PRO2 HDBT70ECO Hdbaset HDMI Extender 70M 4K@30Hz 40M 1080P 70M

Image 1
Image 2
Image 3
Image 4
Image 5
$306

Collect 306 Everyday Rewards points

Log in to MyDeal to link your card
Sold & shipped by Radio Parts
Secure ways to pay at checkout

HDBaseT is the only technology with the ability to distribute truly uncompressed ultra-high-definition A/V for distances of up to 100m/328ft., either point-to-point or daisy-chained, and with zero latency.? The HDBT70MECO can transmit the distance up to 70M for 1080P and 40M for 4K@30Hz signal._


Features
  • HDBaseT Technology
  • Extend HDMI & IR via a signal Cat5E/6 cable_
  • Transmission distance up to 70M for 1080P and 40M for 4K@ 30Hz
  • POC ( Power over the cable), The receiver is powered by the transmitter via the Cat5e/6 cable._
  • HDCP2.2/1.4 compliant
  • LED indicators to show the power status.
  • ESD protection inside the unit
  • Mounting ears attached
  • Bidirectional Infrared Remote supported
  • Phoenix RS232 Port for firmware update or RS232 control signal transmission with an easy panel switch
  • Supports CEC_
Specifications
  • Operating Temperature Range: -5 to +35°C (-41 to +95 °F)
  • Operating Humidity Range:_5 to 90 % RH (no condensation)
  • Input Video Signal: 0.5-1.0 volts p-p
  • Input DDC Signal: 5 volts p-p (TTL)
  • Video Format Supported:___DTV/HDTV;_4K/1080P/1080i/720P/576P/480P/576i/480i
  • Output Video: HDMI 2.0+HDCP1.4/2.2
  • Output Audio: Support DTS-HD, Dolby-HD
  • Maximum Transmission Distance: 70 meters for 1080P, 40 meters for 4K @30Hz
  • Power Supply: 12V2A_with lock ring
  • Poc: Power from TX to RX over Cat5/6 cable
  • Power Consumption: 2.5W (TX) 5W (RX)
  • Dimensions:_105mm H×71mm W×25mm D
  • Weight (Main unit) : 0.7Kg / 1.54lb (Pairs)_

What is in the box?_
  • Transmitter with the mounting ear x 1pc
  • Receiver with the mounting ear x 1pc
  • IR emitter x 2pcs
  • IR receiver x 2pcs
  • 12V 2A Power supply x 1pc (TX)
  • Phoenix plug for RS232 x 2pcs
  • User manual x 1pc
