Description:

The HDMI Over Cat5/6 Extender is ideal for extending digital video and audio, making it a great solution for digital signs, schools, churches, trade show presentations, or any application where the HDMI source is farther than 50 feet from the display.

Note:

1) Cat5e/6 cable is needed to pair the RX&RX. Pure copper conductor is a basic for a qualified ethernet cable.

2) Pls use HDMI ATC certified cable to pair the video source and Display.The HDMI cable must be of copper conductor with all pins wired and shielded.

•


  High-Definition Support: Delivers resolutions up to 1080p @ 60Hz, ensuring clear and vibrant visuals.






•


  Extended Transmission: Transmits HDMI signals up to 50 meters (164 feet) over a single Cat5e/6 cable.






•


  Broad Compatibility: Supports various resolutions including 480i/p, 576i/p, 720p, and 1080i/p.






•


  Durable Build: Constructed with a sturdy black casing to withstand rigorous use.






•


  Efficient Power Consumption: Transmitter consumes 2W; Receiver consumes less than 2W.






•


  Operating Temperature: Designed to function optimally between 0oC to 60oC.




Features:

HDMI Signal: HDMI 1.3V
Resolutions: 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz
Network Cable: UTP/STP Cat6/6A/7
Transmission distance: Up to 50 meters/164 feet transmission distance for 1080p Full HD over single network cable
Working Temperature: 0oC~60 oC
Power Supply : DC5V/1A
Power Consumption : TX: 2W; RX < 2W
Color: Black

Package contents:

• HDMI extender kit Mainbody



• USB power cable X2
