Buy Intel Xeon Silver 4514Y CPU 16 Core / 32 Thread - 2.0GHz - 30MB Cache - LGA 4677 - 150W TDP - 2S [BX807224514Y]

Intel Xeon Silver 4514Y CPU 16 Core / 32 Thread - 2.0GHz - 30MB Cache - LGA 4677 - 150W TDP - 2S

Intel® Xeon® Silver Processor
Intel® Xeon® Silver processors deliver essential performance, improved memory speed, low latency, and power efficiency. They offer the hardware-enhanced performance required for entry-level data center compute, network, and storage.

Built-in Intel Accelerators for Performance and Security
Intel® QuickAssist Technology (Intel® QAT)
Accelerate data compression and encryption while freeing up processor cores to reduce system resource consumption and TCO.
Intel® Advanced Matrix Extensions (Intel® AMX)
Accelerate your CPU’s AI capabilities with improved deep learning training and inference performance.
Intel® Trust Domain Extensions (Intel® TDX)
Increase confidentiality at the virtual machine (VM) level while enhancing privacy and control over your data.
See All Accelerator Engines
Boost performance, reduce costs, and improve power efficiency for demanding workloads with built-in Intel® Accelerator Engines.
Confidently Deploy Common and Emerging Workloads
Whether it is empowering solid foundations for AI innovation and HPC, supporting critical workloads at the edge, building a secure cloud, or helping professionals stay productive, there is an Intel Xeon processor designed to meet your organization's computing needs.

Essentials

Product Collection
5th Generation Intel® Xeon® Scalable Processors

Code Name
Products formerly Emerald Rapids

Vertical Segment
Server

Processor Number
4514Y

Lithography
Intel 7

CPU Specifications

Total Cores
16

Total Threads
32

Max Turbo Frequency
3.4 GHz

Processor Base Frequency
2 GHz

Cache
30 MB

Intel® UPI Speed
16 GT/s

Max # of UPI Links
2

TDP
150 W
Intel® Speed Select Technology - Performance Profile (Intel® SST-PP)

Config - Active Cores - Base Frequency - TDP

4514Y (0) - 16 - 2.0 - 150
4514Y (1) - 12 - 2.1 - 135
4514Y (2) - 8 - 2.6 - 135

Supplemental Information

Embedded Options Available
Yes

Use Conditions
Server/Enterprise

Memory Specifications

Max Memory Size (dependent on memory type)
4 TB

Memory Types
Up to DDR5 4400 MT/s (1DPC & 2DPC)

Max # of Memory Channels
8

ECC Memory Supported
Yes

Expansion Options

Scalability
2S

PCI Express Revision
5.0

Max # of PCI Express Lanes
80

Package Specifications

Sockets Supported
FCLGA4677

Package Carrier
E1B

DTS Max
90 °C

TCASE
79

Package Size
77.5mm x 56.5mm

Advanced Technologies

Intel® On Demand Activation Model
Yes

Intel® Data Streaming Accelerator (DSA)
1 default devices

Intel® Advanced Matrix Extensions (AMX)
Yes

Intel® Speed Select Technology – Core Power
Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes

High Priority Cores
NA

Intel® Resource Director Technology (Intel® RDT)
Yes

Intel® Speed Shift Technology
Yes

Intel® Turbo Boost Technology
2.0

Intel® Hyper-Threading Technology
Yes

Intel® Transactional Synchronization Extensions
Yes

Intel® 64
Yes

Instruction Set Extensions
Intel® AMX, Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512

# of AVX-512 FMA Units
2

Intel® Volume Management Device (VMD)
Yes

Security & Reliability

Intel® Trust Domain Extensions (Intel® TDX)
Yes

Intel® Crypto Acceleration
Yes

Intel® QuickAssist Software Acceleration
Yes

Intel® Platform Firmware Resilience Support
Yes

Intel® Control-Flow Enforcement Technology
Yes

Intel® Total Memory Encryption - Multi Key
Yes

Intel® Total Memory Encryption
Yes

Intel® AES New Instructions
Yes

Intel® Software Guard Extensions (Intel® SGX)
Yes with Intel® SPS

Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX
64 GB

Intel® OS Guard
Yes

Intel® Trusted Execution Technology
Yes

Execute Disable Bit
Yes

Intel® Boot Guard
Yes

Mode-based Execute Control (MBEC)
Yes

Intel® Virtualization Technology (VT-x)
Yes

Intel® Virtualization Technology for Directed I/O (VT-d)
Yes

Intel® VT-x with Extended Page Tables (EPT)
Yes
- MPN: BX807224514Y
