AIPHONE IXWMA IP Relay 4 X IP - 10 X O/P IXW-MA

Image 1
Image 2
Image 3
Image 4
Hurry! 2 items left!
$695

Collect 695 Everyday Rewards points

Log in to MyDeal to link your card
Sold & shipped by Radio Parts
Secure ways to pay at checkout
Aiphone - IXW-MA IP RELAY, 4 INPUTS, 10 OUTPUTS

The IXW-MA is a multi-purpose adaptor for the IX Serieswith 4 contact inputs and 10 relay outputs.

The inputs on the IXW-MA can be used to send a command to a specific station to perform a task.

The IXW-MA relays are associated to a specific station and programmed to change state when relay output 1 or 2 on the associated station changes state.

The IXW-MA is a PoE device, and can be programmed via IX Series Support Tool 5.0 or later.

_

FEATURES
  • New features available for North America with a firmware update
  • Program using the IX Series 2 Support tool
  • Powered over POE, no additional power supply required!
  • Allows connection of theto an IX Series system
  • 4 activation inputs, 10 relay outputs
  • Line Supervision events from IX Series master can trigger a relay closure
  • Activate with either relay output from IX series stations

Specifications

Power Source: 802.3af PoE compliant

Power Draw: Standby: 43 mA; Maximum: 135 mA

Relay Output: Relays 1-4: Form C 24V AC/DC 500mA - Relays 5-10: Form A 24V AC/DC 500mA

LAN: Ethernet (10BASE-T, 100BASE-TX)

Protocols: IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, SMTP, SFTP, DHCP, NTP, DNS

Encryption system: TLS1.0, TLS1.1, TLS1.2

Port Security: IEEE 802.1X

Operating Temp: 14° ~ 104°F (-10° ~ 50°C)

Dimensions: 7-1/2" x 9-5/8" x 13/16"

Weight: 1.39 lbs

_


Weight: 1.049

Aussie Stock
All our stock is kept in our Melbourne based warehouse. Our stock levels are also updated every 10 minutes! So if it says 10 units in stock, you can trust that it is accurate.

No PO Boxes or Parcel Lockers
At this stage we only use couriers and can only deliver to a road-side address. This means PO Boxes and Parcel Lockers cannot be accepted as StarTrack do not deliver to these addresses.
In instances where a PO Box or Parcel Locker address in entered, we may ask for an alternative road-side address, or cancel and refund your order immediately and urge you to replace your order with an alternative delivery address.

Delivery times
We typically dispatch our goods same day or next day. From there, you can expect 2 - 8 business days Australia wide. Most capital cities can expect 1-2 day delivery times.
Any RTS (Return to Sender) orders due to missing or incorrect address information entered by the buyer may incur an additional charge for redelivery.

GTIN: 4968249651864

Estimated Delivery Time Frame:4-8 business days
