Maxsn Motherboard Icraft Z790Itx Wifi Intel Z790 Lga1700
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
Collect 509 Everyday Rewards points
Dispatch in 2 business days
Collect 509 Everyday Rewards points
Dispatch in 2 business days
[MAXSN / MOTHERBOARD] ICRAFT Z790ITX WIFI/INTEL Z790 LGA1700/ITX/2X DDR5, MAX96GB/2X M.2
iCraft Z790ITX WIFI
Intel Core 14th Gen CPU
9 phases power supply
90A Dr.Mos
RAA229131 PWM
Hybrid cooling system
DDR5 XMP 7400MHz+
2.5G LAN
2*20G Type-C
SPECIFICATIONS
Audio: Realtek® ALC897 Codec, 5.1-Channel High Definition Audio
Chipset: INTEL Z790
Form Factor: ITX 172mm x 172mm
I/O Connectors: Front USB (Total 6 ports): 1x USB 3.2 Gen2 Type C, 2x USB 3.2 Gen1 Type A, 3x USB 2.0; *Rear USB (Total 9 ports): 1x USB 3.2 Gen2x2 Type C, 4x USB 3.2 Gen1 Type A, 4x USB 2.0
Integrated CPU Graphics: 1x DisplayPort 1.4, 1x HDMI™port
LAN: Realtek® RTL8125BG 2.5G LAN
PCI Slots: 1x PCIe 5.0 x16 slot
Processor Support: Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
RAID: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
RAM Type/Bus/Max: 2x DDR5, Maximum Memory Capacity 96GB; Memory Support DDR5 7400+(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz; Supports Intel® XMP 3.0 OC; Supports Dual-Controller Dual-Channel mode
Socket: LGA 1700
Storage Interface: M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode), M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode), 4 x SATA 6Gb/s ports
Weight
Wireless & Bluetooth: Intel® Wi-Fi 6E AX211, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps, Supports 802.11 a/ b/ g/ n/ ac/ ax, Supports Bluetooth® 5.3
PACKAGE CONTENTS
1 x Maxsn Motherboard Icraft Z790Itx Wifi Intel Z790 Lga1700
SKU: MS-IC-Z790ITX-WIFI
