MILESIGHT LORAWAN ULTRASONIC DISTANCE/LEVEL SENSOR

Milesight em310-udl is a lora au915/as923 ultrasonic distance iot sensor mainly for the detection of waste bin and other container’s fill level. With a compact size and wide measure range, em310-udl can be installed to any types of waste bins or containers to monitor solid or liquid level. Besides, em310-udl equips with 3-axis accelerometer to detect the status of container cover. Compliant with milesight lorawan® gateway and milesight iot cloud solution, users can know the container status and fill-in level in real-time via browser or mobile app remotely.

FEATURES

3-450 cm wide measuring range with short blind zone

Easy to install, suitable for various types of waste bins or containers

Built-in 3-axis accelerometer sensor to monitor device tilt status

IP67 waterproof and salt pray resistant enclosure for outdoor applications and easy to clean

Ultra-wide-distance wireless transmission up to line of sight of 15 km

Equipped with NFC for one touch configuration, support card emulation mode

Function well with standard LoRaWAN® gateways and network servers

SPECIFICATIONS

Frequency: AU915/AS923

Tx Power: 22 dBm

Sensitivity: -137 dBm @300bps

Mode: OTAA/ABP Class A

Distance Detection Range: 3 - 450 cm

Detection Accuracy: ± (1+0.3%*S) cm, S=distance)

Distance Resolution: 1 mm

Device Position Status: Normal/Tilt

Power Supply: 2 × 3500 mAh ER17505 Li-SOCl2 battery

Battery Life: Up to 10 years (10 min interval + 20 triggers per day)

Operating Temperature: -15°C to +60°C

Relative Humidity: =90% (non-condensing)

Ingress Protection: IP67

Dimension: 111 × 62 × 40 mm

Material & Color: ABS, Black

Installation: On the flat surfaces with screw

PACKAGE CONTENT

1 x Milesight Lorawan Ultrasonic Distance Level Sensor

1 x Mounting Screws

1 x Screw caps

SKU: EM310-UDL-915M
