Morningstar TriStar 60 Amp Solar Controller

The Morningstar TriStar is a three-function controller that provides reliable solar battery charging, load control or diversion regulation.



Features:

  • Large heat sink and conservative design enables operating at full ratings to 45°C
  • Optional meter displays extensive system and controller information, automatic self-test and reset. Displays in 5 languages
  • RS-232 connects to a personal computer for custom settings, data logging and remote monitoring and control
  • DIP switch provides user with choice of 7 digital presets. Additional custom settings via RS-232
  • Fully protected against reverse polarity, short circuit, over current, high temperature and over voltage



Specifications:

Amps 60.0 Amps
Operating Temperature Range –40°C to +60°C
Dimensions (LxWxH mm) 260 x 127 x 71
Output System Voltage 12-48V
Load Current Rating 60A
Rated Solar Input 60A
Weight (kg) 1.6
Manufacturers Warranty 5 Years


Note: If this product is being used for Lithium, please contact us before placing the order. This product needs to be programmed before it is able to be used for Lithium so a special order needs to be placed
