MSI A320M PRO M2 AMD mATX Motherboard - AM4 Ryzen 2xDDR4 3xPCI-E 1xM.2 6xUSB3.1

Image 1
Shop More Products

MSI A320M PRO M2 AMD mATX Motherboard - AM4 Ryzen 2xDDR4 3xPCI-E 1xM.2 6xUSB3.1 6xUSB2.0 1xDVI-D 1xVGA 1xHDMI LS...

MSI A320M PRO M2 AMD mATX Motherboard - AM4 Ryzen 2xDDR4 3xPCI-E 1xM.2 6xUSB3.1

MSI A320M Pro M2 AMD m-ATX Motherboard - AM4 Ryzen 2xDDR4 3xPCI-E 1xM.2 6xUSB3.1 6xUSB2.0 1xDVI-D 1xVGA 1xHDMI

AMD AM4 motherboard inspired from architectural design, with Core Boost, DDR4 Boost, Turbo M.2
Supports AMD Ryzen 1st and 2nd Generation/ Ryzenâ„¢ and Athlonâ„¢ with Radeonâ„¢ Vega Graphics / A-series and Athlonâ„¢ X4 Processors for Socket AM4
Supports DDR4 Memory, up to 3200+(OC) MHz
Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.
DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability.
Audio Boost: Reward your ears with studio grade sound quality.
EZ Debug LED: Easiest way to troubleshoot
X-Boost: Software that auto-detects and allows you to boost the performance of any storage or USB device.
Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.
PCI-E Steel Slot: Protecting VGA cards against bending for better performance, stability and strength.
SOCKET AM4
CPU (MAX SUPPORT) Ryzen
CHIPSET AMD A320 Chipset
DDR4 MEMORY 1866/ 2133/ 2400/ 2667(OC)/ 2933(OC)/ 3200(OC)+ MHz
MEMORY CHANNEL Dual
DIMM SLOTS 2
MAX MEMORY (GB) 32
PCI-E X16 1
PCI-E GEN Gen3
PCI-E X1 2
SATAIII 4
M.2 SLOT 1
RAID 0,1,10
TPM (HEADER) 1
LAN 10/100/1000*1
USB 3.1 PORTS (FRONT) 2(Gen1, Type A)
USB 3.1 PORTS (REAR) 4(Gen1, Type A)
USB 2.0 PORTS (FRONT) 4
USB 2.0 PORTS (REAR) 2
SERIAL PORTS(FRONT) 1
AUDIO PORTS (REAR) Realtek ALC887 Codec
DVI-D 1
VGA 1
HDMI 1
DIRECTX 12
FORM FACTOR m-ATX
OPERATING SYSTEM Support for Windows 10 64-bit, Support for Windows 7 64-bit, * To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.

SKU: MB-MSI-A320M-PR

Reference ID: 1572576
