200mW 648nm Red Line Laser Module Generator Variable Focus Industrial Marking Position Alignment Diode Generator w/ Locking Ring
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
Description:
This variable focus 150mW 648nm red line laser module employs qualified 648nm red laser diode, generates the stable and reliable red laser line applicable for various industrial alignments and positioning work. Compact size, easy to install, multi-angle adjustment of installation, easy to operate.
Specification:
Wavelength��648nm
Beam Shape��Line
Variable Focus��YES
Output Light��Visible Light
Working Voltage��DC 5V
Working Current��210mA
Optics��Focus Lens + Glass Wave Line Lens
Shell Material��Aviation Aluminum
Operation Temperature����50��
Service Life��8000h
Dimension (D*L)��16mm x 68mm (With Locking Ring)
Features:
1. 200mW stable output power, variable focus, 648nm red line laser module.
2. Good heat dissipation ensures its long service life.
3. Designed with locking ring, ensure its anti-interference performance, high stability under vibration condition.
4. Come with mount holder, rotate the adjust the angle for easy placement and installation.
5. Widely used in laser alignment, positioning for sewing equipment, embroidery machine, and other industrial, medical and laboratory equipment.
6. The specification of international standard master interface DC is 5.5*2.1mm
Caution:
1. Light is emitted from the aperture. Avoid Direct Eye Exposure. Keep Away from Children and Pets;
2. Wear protective glasses for close use.
Package Included:
1 x Red Line Laser Module
1 x Power Adapter
1 x Mount Holder
GTIN: 5202984983217
Reference ID: 2679824
