The NLS 30835 is a sturdy 16-amp, 4-pole RCBO designed for dependable electrical protection. It combines overcurrent and residual current safety, reducing electrical hazards and meeting the latest AS/NZ 61009-1 standards. Its Type A classification detects sinusoidal AC residual currents for enhanced protection.

• 6kA Breaking Capacity: Protects against overloads and short circuits.
• Compact Build: Measures 84mm H x 71mm W x 80mm D, perfect for tight spaces.
• User-Friendly Design: DIN rail mounting and lockable toggles simplify installation and use.
• Earth Leakage Sensitivity: 30mA for accurate fault detection.
• Versatile Voltage: Works with 240V and 415V systems.
• Durable Terminals: Supports cables up to 25mm² for secure connections.

Q: What is the RCBO’s breaking capacity?
A: It offers a reliable 6kA breaking capacity, safeguarding against overcurrent issues.

Q: Can it be used in three-phase systems?
A: Yes, its 3P+N configuration protects three phases and neutral effectively.

Q: Does it meet Australian standards?
A: Absolutely, it complies with AS/NZ 61009-1 for safe, standard-compliant installations.
