OBDSTAR iScan Marine Diagnostic Code Scanner For Yamaha Boat, Jet Ski

Image 1
Image 2
Image 3
Image 4
Hurry! 4 items left!
$649

Collect 649 Everyday Rewards points

Log in to MyDeal to link your card
Free Shipping

Dispatch in 2 business days

Sold & shipped by Elite Electronics
Secure ways to pay at checkout
OBDSTAR ISCAN YAMAHA Marine Scanner

ISCAN YAMAHA is a highly efficient portable scanner tablet specifically designed for YAMAHA, featuring a sleek and industrial appearance. This state-of-the-art device is part of the new generation of intelligent marine diagnostic equipment, meticulously customized for customers. Equipped with a powerful RK3128 quad-core processor and a 5.0-inch capacitive touch screen, ISCAN YAMAHA ensures a professional and seamless diagnosis experience for customers.


  • New Android 5.1.1 operating system
  • Simple and intuitive menu guidance for quick mastery of equipment operation
  • Complete diagnostic functions, including code reading, code clearing, data flow, action test, setting, coding, etc.
  • Convenient and quick menu arbitrary selection
  • Record and play back real-time data flow to accurately locate sensor and component faults
  • Wi-Fi connection to the internet for one-click software upgrades
  • One-click remote function for OBDSTAR technical staff remote assistance

Advanced Function
  • The OBDSTAR mobile app combines functions such as diag socket location, flash code query, technical bulletin, manual service function (service lamp reset), basic parameters, etc. to work with ISCAN and improve marine diagnosis accuracy and efficiency.
  • Multiple data flow display modes, such as text, waveform diagram, and instrument diagram, make fault analysis easy.
  • Special functions, such as Device Configuration and Maintenance Notification Setting, are supported.

Diagnostic support series
  • Supports all Yamaha Jet Ski models from 2003 to 2022.
  • Supports all Yamaha Outboard models up to 2022.






  • Operating System: Android 5.1.1
  • CPU: RK3128 quad-core ARM cortex A7
  • Battery: 2600mA, rechargeable polymer lithium battery
  • Extension Memory Card: 32G micro SD (TF) card supported
  • LCD: 5.0 inch
  • LCD Resolution: 800*480
  • Touch Screen: Capacitive touch screen
  • Wifi: Supported
  • Working Temperature: -20 to 55℃ (-4℉ to 131℉)
  • Storage Temperature: -20℃ to 70℃ (-4℉ to 158℉)
  • Weight: About 700g
  • Dimensions: 198mmx115mmx31mm


* DISCLAIMER: Design, features and specifications subject to change without notice. Some features in videos on the Internet may not be available on all models, please contact us for the TECHNICAL SPECIFICATIONS for a complete list of features by model. This feature list is for reference only, please contact us to verify features and functionality.

GTIN: 7331898815791
