G.A.S RadAir Mixed Flow Fan | 5 Inch | 125mm
G.A.S RadAir Mixed Flow Inline Fans: Your Affordable, High-Performance Ventilation Solution
The G.A.S RadAir Mixed Flow Inline Fans are the gardener's dream come true - a plug-and-play solution that's not only easy to use but also incredibly cost-effective. These fans offer an excellent value for your money, delivering high-power performance while keeping noise levels to a minimum. They excel at moving significant volumes of air with high air pressure, making them an ideal choice for various horticultural applications.
Key Features:
- Efficient Guide Vanes: These fans incorporate guide vanes that serve to straighten airflow, boosting air pressure for optimal performance.
- Sleek Inline Housing: The RadAir fans feature a sleek and practical inline housing design that seamlessly fits into your setup.
- Secure Flange: A generous flange provides a secure and stable connection for your ducting.
- Speed Control Compatibility: These fans are compatible with speed control options, allowing you to fine-tune your ventilation setup.
- Model Variety: The RadAir range offers models that can move air volumes ranging from 200 to 2300 m3/h, catering to a variety of needs.
- Plug-and-Play: With straightforward IEC plug connectors, installation is a breeze.
- Simple Maintenance: RadAir fans are easy to maintain, with a user-friendly design that allows for hassle-free cleaning.
Housing Design: The RadAir housing design includes a built-in mounting bracket for easy installation and maintenance. Its sleek, sealed body ensures a secure and efficient setup.
Routine Maintenance: To ensure these fans continue to deliver optimum performance, regular maintenance is essential. Fortunately, the RadAir fans are designed with ease of maintenance in mind.
Removing RadAir Fans from the Housing: Cleaning the fans is a straightforward process. To access the fans for cleaning, simply detach the IEC plug, undo the two molded thumbscrews, and remove the motor unit from the housing.
Specifications:
- RadAir 100: Size (100mm / 4"), Sound Level (30 dB), Max Air Flow (200 m3/h)
- RadAir 125: Size (125mm / 5"), Sound Level (30 dB), Max Air Flow (200 m3/h)
- RadAir 150: Size (150mm / 6"), Sound Level (35 dB), Max Air Flow (500 m3/h)
- RadAir 200: Size (200mm / 8"), Sound Level (50 dB), Max Air Flow (850 m3/h)
- RadAir 250: Size (250mm / 10"), Sound Level (60 dB), Max Air Flow (1500 m3/h)
- RadAir 315: Size (315mm / 12"), Sound Level (66 dB), Max Air Flow (2300 m3/h)
For cost-effective, high-performance ventilation solutions, the G.A.S RadAir Mixed Flow Inline Fans are your answer. Enjoy hassle-free installation and maintenance, as well as impressive air-moving capabilities for your horticultural needs.
