SHOW MATRIX-A6 Digital Audio Matrix Processor 6 Analog In X 6 Analog Out
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
Collect 1145 Everyday Rewards points
Collect 1145 Everyday Rewards points
MATRIX-A6 is a dedicated music, paging, discussion, and zone management solution for commercial audio applications. It has 6 inputs and 6 outputs in a single device powered by a state-of-the-art DSP platform._
Modle | MATRIX-A6 |
Connectors | Euroblock 3 x 6-pin, 5mm pitch |
CODEC | 32-bit, 48K/96K |
MIC/ Line Inputs | Active balanced |
Gain Settings | +10 to +60dB,1dB steps |
Input Impedance | 6.8K |
Phantom Power(±3V) | +48VDC |
THD+N | < 0.03%, typ 20Hz-20KHz, 0dBu A-Weight |
Maximum Input | +20dB |
Frequency Response | 20Hz-20KHz, at 0dBu- 1.5dB A-Weight |
Dynamic Range | 108dB |
Crosstalk | <-88dB, at 20Hz-20KHz, 0dB, CH to CH |
Digital Gain Range | 0~-48dB Steps=12dB |
Outputs | Active balanced |
Impedance | 200 |
Maximum Output | +20dBu |
Frequency Response | 20Hz~20KHz at 0dBu ±1.5dB A-Weight |
Dynamic Range | 108dB |
Crosstalk | <-88dB, at 20Hz-20KHz, 0dB, CH to CH |
Indicators | |
Signal | -40dBu Green LED |
Overload | +19dBu Max, A-Weighted |
DSP | |
Processor | 32/64-bit Floating Point |
Power Supply | 100-240V/50~60Hz |
Dimension (W x H x D) | 483 x 44 x 256 mm (19.02 " x 1.73" x 10.08 ") |
_
_
GTIN: 4712646009175
Estimated Delivery Time Frame:4-8 business days
Ask a Question About This Product
Reference ID: 11705693
