SRNE VOLTX 30A MPPT Solar Charge Controller 12V/24V Adjustable LCD Display Solar Panel Regulator for Gel Sealed Flood and Lithium Batteries

SRNE VOLTX 30A MPPT Solar Charge Controller 12V/24V Adjustable LCD Display Solar Panel Regulator for Gel Sealed Flood and Lithium Batteries

Price
$149.99
Earn 3x points and collect 447 Everyday Rewards points. Promotion ends 16/05/2024.
Create a MyDeal Account or Login to link your card
Shipping
Free Shipping

Quantity
Maximum item limit (402) has been reached.

SRNE VOLTX MPPT Solar Charge Controller Makes Your Energy Management More Efficient!

[Advanced Maximum Power Point Tracking]
This serie controller adopts the industry-leading MPPT which tracking efficiency up to 99.9% to achieve the maximum energy trackingfor the solar panel, that is, it can quickly and accurately track the maximum power point of the solar battery on any condition.

[Temperature Sampling and Control]
Fitted with a Remote Temperature Sensor, the MPPT Charge Controller can measure battery temperature in real-time. Connect the temperature sensor to the corresponding temperature interface to achieve the high and low temperature protection for the battery and the temperature compensation for the charging voltage of lead-acid battery (no temperature compensation for the lithium battery) , assuring stable and constant charging.

[Support TTL & RS485 & CAN & Bluetooth Communication]
MPPT solar charge controller has powerful TTL and RS485 communication protocol function. By connecting the controller with other devices, you can easily obtain the status information of the charger, adjust battery charging parameters, etc. and under the Bluetooth Communication you can view fault status through the mobile app.

[Intelligent Protection Functions]
MPPT provides multiple protection functions: Over-temperature protection of device, Battery over-temperature protection, Input over-power protection, PV input side too high voltage protection, PV input reverse-connection protection, Reverse charging protection at night.

[Max. Solar Input Power 12V/400W 24V/8000W]
The MPPT charge controller can work with standard off-grid 12/24V solar panels. In particular, this controller will significantly increase the efficiency of a solar system where the solar panel voltage is much higher than the battery voltage.

ELECTRICAL PARAMETERS
  • Static power consumption: ≤30mA
  • Battery Type: USE/FLD/GEL/LI/SLD(Default)
  • System voltage: 12V/24V
  • Battery's operating voltage range: 8V-32V
  • Rated charging current: 30A
  • Maximum PV Input Current: 27A
  • Maximum solar panel power: 400W/12V; 800W/24V
  • Maximum PV open-circuit voltage: 150V
  • MPPT operating voltage point range: (Battery Voltage +2)~110V
  • MPPT tracking efficiency: >99%
  • Charging conversion efficiency: 85%-98% (10%-100% of rated power)
  • Rated load current: 30A
  • Load operating mode: Pure light-dependent control, light and time-dependent control, manual mode (default), debugging mode, normally opened.
  • TTL communication: Baud Rate 9600kps
  • RS485 communication: One isolated RS485 communication port, with power output of 5V200mA, baud rate of 9,600kps by default and adjustable.
  • Bluetooth communication: Built-in
  • CAN communication: RV-C Protocol
  • Historical data: Can store historical data of the past 300 days
  • Protection function: PV Overvoltage Protection, PV Reverse Connection Protection, PV Short-Circuit Protection, Nighttime Reverse Charge Protection, Input Limited Power Protection, Overtemperature Protection, Load Short-Circuit Protection, Load Overload Protection, Battery Supervoltage/Over-discharge Protection, Battery Reverse Connection Protection and Battery Terminal Short-Circuit Protection.
  • Grounding type: Co-negative design and negative grounding
  • Cooling mode: Natural Cooling
  • Parallel connection for charging: No
  • Charging voltage line loss compensation: No
  • Support full settings: Yes
  • Constant voltage output setting: Yes
  • Charging temperature compensation of lead-acid battery: Yes
  • Temperature protection: Yes
  • Overload/short-circuit protection: Yes
  • Load pre-start: Yes


  • ENVIRONMENTAL DATA
  • Protection grade: IP32
  • Operating ambient temperature range: -35°C~ 65°C (no derating within 45°C if well ventilated)


  • MECHANICAL SPECIFICATIONS
  • Dimension: 260x216x83.2mm
  • Mounting hole spacing: 200 mm
  • Weight: 2.3kg
  • Fixed hole position: Φ10mm

  • GTIN: 9355348054859
