SRT7014 STRONG HD Twin Tuner 500Gb DVR AV Input & Rs232 Twin HD Tuner HD TWIN TUNER 500GB DVR
2 Reviews
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
2 Reviews
The SRT 7014 offers the usual STRONG DVR features; 500GB Hard Drive, Twin Tuners, Multimedia playback, it also supports a Component & Composite AV Input to record fromexternal devices; such as Camcorder, CD, DVD, Pay TV and game consoles.
But back to the TV; the SRT 7014 features Smart Series Record, you can record every episode of your favourite TV program in simple steps, you don't even need the internet connection for this feature.
The Twin Tuners allow you to record up to 3 programs while watching a 4th (from 2 networks) or a pre-recorded program.
Audio/Video IN/OUTPUT | |
Audio L/R | RCA/Cinch, Volume and Mute control |
Audio/Video Input | RCA/Cinch A/V Input x1 & Component Input (YCbCr) x 1 - via External devices, 576i input only |
S/PDIF | Optical digital audio output |
Video | RCA/Cinch, Video Outputs (CVBS). Component output (YPbPr). HDMI (High Definition Multimedia Interface). S- Video |
Data Port | |
Ethernet | 1 x port RJ45, 10/100MB-Tx (for data transfer and internet access) |
RS-232 Serial | 9pin D-sub male, Max 115K bps |
SD Card Slot | Support SD card slot on front panel |
USB | USB 2.0 Host (USB Port x 1 front panel & 1 rear panel), A-type |
General Data | |
Dimensions | 335 x 247 x 58.5mm (WxDxH) |
Weight | 3kg |
MPEG Transport Stream & AVDecoding | |
Audio Codecs | MPEG1/2/3 (MP3), Digital Dolby, Digital Dolby Plus, Window Media & Media Pro Audio |
Audio Decoding | Digital Dolby Plus |
Audio Mode | Stereo/Joint Stereo/Mono |
Profile Level | MPEG-II MP@ML, MPEG-IIMP@HL, MPEG-IV AVC.H.264 HP@L4.0 |
Sampling Rate | 32KHz, 44.1KHz and 48KHz |
Transport Stream | MPEG-II ISO/OEC 13818-1 |
Video Codecs | MPEG, MPEG4, HD Divx3.11/4.11/5x/6x, Home Theatre |
Video Resolution | 720 x 576, 1280 x 720P, 1920 x 1080i, 1080P |
Power Supply | |
Input voltage | AC100~240V, 50~60Hz |
Power Consumption | Standby <1W, on mode Max 50W |
System Resources | |
DDR SDRAM | 128Mbyte x 2 |
EEPROM | 256Kbit |
FLASH | 8Mbyte |
Inbuilt Hard Disk Drive | 500GB Hard Drive |
Processor | 32bit processor (450MHz) |
Tuner | |
Carrier Mode | 2k and 8k mode |
Code Rate | 1/2, 2/3, 3/4, 5/6, 7/8 |
Frequency Range | 170 ~ 230 MHz (VHF) 470 ~ 862MHz(UHF) |
Guard Interval Modes | 1/4, 1/8, 1/16, 1/32 |
IF Bandwidth | 7.8 MHz |
Input Impedance | 75 d |
Waveform | COFDM |
_
_
What's in the Box?
1 X STRONG Digital Video Recorder - SRT 7014
1 X Remote Control & batteries
1 X Users Manual
1 x Set AV Leads & Wi-Fi Dongle
_
_
_
_
_
MPN: SRT7014
Reference ID: 697350
