StarTech Mini DisplayPort to DisplayPort Multi Monitor Hub - 2-Port Daisy Chain Splitter

Supports up to 43840x2160 @ 30hz

This MST hub lets you connect two DisplayPort monitors to your Mini DisplayPort computer. MST works on any Windows® device that supports DisplayPort 1.2, such as models of the Lenovo™ Think Pad® and Microsoft® Surface™. When connected to earlier revisions of DisplayPort, such as DP 1.1 the MST hub acts as a video splitter. The MST hub is USB powered, so the only thing you'll need to operate the hub is your computer.

Increase your productivity with multiple monitors

The newest generations of laptops are more portable than ever, unfortunately this means you?re left with fewer video outputs and a small integrated screen. The MST hub solves these problems by letting you connect two independent displays to a single mDP port on your computer, which makes multitasking much easier. Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display, which makes it easier to multitask and increase your productivity - perfect for creating an easy-to-dock hot desk solution with a wireless keyboard and mouse peripheral set. You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage.

Astonishing picture quality that won?t drain your system resources

MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. 4K is supported by the latest A/V devices and delivers four times the resolution of 1080p. Plus, because the MST hub can output high-definition 1080p, the MST hub is perfect for all high-resolution applications such as graphic design and medical imaging.

Works with any monitor, television or projector

With this MST hub, you can use separate mDP video adapters to connect HDMI, VGA or DVI displays, for compatibility with all of your existing monitors. The hub is VESA and DisplayPort certified to support DP 1.2 enabled systems, for seamless integration with your existing video equipment.

The MSTMDP122DP has been certified by Microsoft and tested for compatibility with your Microsoft Surface Pro 3, Surface Pro 4 and Surface Book and is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Connector(s)
Connector A	Mini-DisplayPort (20 pin) Male Input
Connector B	DisplayPort (20 pin) Female Output
Environmental
Humidity	50-90%
Operating Temperature	0?C to 40?C (32?F to 104?F)
Storage Temperature	-20?C to 60?C (-4?F to 140?F)
Hardware
Audio	Yes
Chipset ID	STDP4320
Converter Type	MST Hub
Output Signal	DisplayPort
Ports	2
Packaging Information
Shipping (Package) Weight	142 g [5 oz]
Performance
Maximum Digital Resolutions	3840x2160 @ 30hz
Supported Resolutions	Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup. Average resolution bandwidth allocation 1920x1080 (High-definition 1080p) @60hz - 22% 1920x1200 @60hz - 30% 2560x1440 @60hz - 35% 2560x1600 @60hz - 38% 3840 x 2160 (Ultra HD 4K) @30hz - 38% Note: Exceeding 100% will reduce functionality.
Wide Screen Supported	Yes
Physical Characteristics
Color	Black
Enclosure Type	Plastic
Product Height	14 mm [0.6 in]
Product Length	62 mm [2.4 in]
Product Weight	51 g [1.8 oz]
Product Width	58 mm [2.3 in]
Power
Power Source	USB-Powered
Software
OS Compatibility	Windows 10 (32/64) Windows 8/8.1 (32/64) Windows 7(32/64)
Special Notes / Requirements
Note	DisplayPort 1.2 with MST+HBR2 support from the GPU is required for independent display output
	When using a DisplayPort 1.1 video card the MSTMDP122DP will act as splitter, automatically mirroring your video source across all displays. Resolution limitations apply
What's in the Box
Included in Package	2-port mDP to DP MST Hub
	Quick install guide

Product Specifics

Specification	Value
Adapter Type	Monitor Adapter
MPN	MSTMDP122DP
Manufacturer Part Number	MSTMDP122DP
Product Condition	Brand New/Unused
SKU	210483
