TMC2209 Stepper Motor Driver Super Silent Stepsticks Mute Driver Board 256 Microsteps For Sidewinder 3D Printer
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
Collect 39 Everyday Rewards points
Dispatch in 2 business days
Collect 39 Everyday Rewards points
Dispatch in 2 business days
Note:
* The tmc2209 stepper motor driver v2.0 version and v3.0 version will send randomly. And?the two versions is universal.
*?The pin header of v3.0 can be cut off. If you don't need it.
Features:
- Hardware compatible with StepStick and Pololu A4988
- Drive capability up to 1.7A (RMS) continuous coil current - 2.8A Peak
- Step/Dir interface with microstep interpolation (up to 256 microsteps)
- Configuration via CFG pins or UART interface
- Motor voltage: 5.5~28V
- Logic voltage: 3.3~5V
- RSense: 0.11 Ohm
- StealthChop2 - for quiet operation and smooth motion
- SpreadCycle - highly dynamic motor control chopper (enableable via UART, OTP, CFG Pin)
- CoolStep - current control for energy savings
- StallGuard4 - sensorless motor load detection
Package included:
1 x TMC2209 Driver
1 x Heatsink
1 x Screwdriver
GTIN: 4191026520880
Estimated Delivery Time Frame:12-20 business days
Ask a Question About This Product
Reference ID: 5999162
