1: Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. The 160 MHz bandwidth is only available on the 5GHz band. It may be unavailable in some regions/countries due to regulatory restrictions. Actual wireless data throughput, wireless coverage, and connected devices are not guaranteed and will vary as a result of internet service provider factors, network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
2: Use of Wi-Fi 7 (802.11be) and features including 160 MHz Bandwidth, 4K-QAM, Multi-RUs, OFDMA and MU-MIMO requires clients to also support the corresponding features.
3: The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
| HARDWARE FEATURES | Interface |
|
|---|---|---|
| Physical Security Lock | No | |
| Button | Reset, LED | |
| Power Supply | 802.3at/bt PoE | |
| Max. Power Consumption |
| |
| Dimensions (W×D×H) | 143mm × 86mm × 40mm (5.6″ × 3.4″ × 1.6″) | |
| Antenna |
| |
| Mounting | Wall Mounting (Kits included) | |
| WIRELESS FEATURES | Coverage | 50m (600ft²)*² |
| Concurrent Clients | 250+*⁴ | |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax/be | |
| Frequency | 2.4GHz and 5GHz | |
| Signal Rate |
| |
| Wireless Functions |
| |
| Wireless Security |
| |
| Transmission Power |
| |
| MANAGEMENT FEATURES | Omada App | Yes |
| Centralised Management |
| |
| Cloud Access | Yes. Requires the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller | |
| Email Alerts | Yes | |
| LED ON/OFF Control | Yes | |
| Management MAC Access Control | Yes | |
| SNMP | v1, v2c, v3 | |
| System Logging Local/Remote Syslog | System Log | |
| SSH | Yes | |
| Web-based Management | Yes | |
| L3 Management | Yes | |
| Multi-site Management | Yes | |
| Management VLAN | Yes | |
| Zero-Touch Provisioning | Yes. Requires the use of Omada Cloud-Based Controller. | |
| ENVIRONMENT | Operating Temperature | 0°C~40°C (32°F~104°F) |
| Storage Temperature | −40°C~70°C (−40°~158°F) | |
| Operating Humidity | 10~90% RH non-condensing | |
| Storage Humidity | 5~90% RH non-condensing | |
| OTHERS | Certification | CE, RoHS |
| Package Contents |
| |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux |
1: Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. The 160 MHz bandwidth is only available on the 5GHz band. It may be unavailable in some regions/countries due to regulatory restrictions. Actual wireless data throughput, wireless coverage, and connected devices are not guaranteed and will vary as a result of internet service provider factors, network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
2: Use of Wi-Fi 7 (802.11be) and features including 160 MHz Bandwidth, 4K-QAM, Multi-RUs, OFDMA and MU-MIMO requires clients to also support the corresponding features.
3: The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
4: Coverage value is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.
5: Omada Mesh, Seamless Roaming, Captive Portal, and Cloud Access require the use of an Omada SDN controller. Please refer to the User Guides of Omada SDN controllers for configuration methods.
