TP-Link Omada AX1800 Wi-Fi 6 Desktop GPON Access Point

TP-Link Omada AX1800 Wi-Fi 6 Desktop GPON Access Point

Hurry! 4 items left!
Price
$199
Collect 199 Everyday Rewards points
Log in to MyDeal to link your card
Shipping
$12.00 Australia-wide (per item)

Quantity
Maximum item limit (4) has been reached.


TP-Link EAP610GP-Desktop Omada AX1800 Wi-Fi 6 Desktop GPON Access Point

• Seamless 1.8 Gbps WiFi 6 Speeds: 1201 Mbps on 5 GHz & 574 Mbps on 2.4 GHz†
• 1× GPON Port for High-Speed and Ultra-Range Access
• Ultra-Broadband WiFi 6: MU-MIMO, Seamless Roaming§
• One Fiber for Multiple Services: Wired, Wireless, Voice, VoIP, Data, and HD Video Services
• VoIP Calls: Support multiple VolP accounts and various call features, exceeding traditional landlines
• Easy Use: One-Click Pairing and Automatic Adoption
• Smart O&M: PPSK△ and Multiple Portals§
• High Flexibility: Support both desktop and wall mounting setups
• Centralized Management: Integrates with the Unified Optical Solution

Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.

  • Use of WiFi 6 (802.11ax) and its features like MU-MIMO, requires clients to support the corresponding features.
  • Seamless Roaming, and Captive Portal require the use of Omada SDN controllers.
  • This feature needs to be used with the switch that supports VPN Server. And at the same time, the Omada controller needs to be used with the switch that supports the Cli Template.
  • The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
  • Coverage value is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.

Specifications:

HARDWARE FEATURES

  • Interface • 1x GPON Port
    • 1x FXS Port
    • 4x Gigabit RJ45 Ports (One Supporting 802.3af PoE Out)
  • GPON Interface
  • Port Type: SC-APC
    • Standards and Protocols: ITU-984.x, G.988, Class B+
    • Data Rate: 2.488 Gbps (Downstream); 1.244 Gbps (Upstream)
    • Fiber Type: 9/125 um Single mode
    • Max. Cable Length: 20 km
  • Button
    • Reset
    • LED
  • Power Supply 53.5V/0.81A DC
  • Max. Power Consumption 17.3W (PoE Out Off)
  • Weight 492g
  • Dimensions ( W x D x H ) 6.9 × 5.5 × 1.3 in (175 × 140 × 33 mm)
  • Antenna Internal Omni
    • 2.4 GHz: 2× 5 dBi
    • 5 GHz: 2× 4.5 dBi
  • Mounting Desktop / Wall mouting (Kits included)

WIRELESS FEATURES

  • Coverage 140㎡(1500ft²)**
  • Concurrent Clients 120+*
  • Wireless Standards IEEE 802.11 a/b/g/n/ac/ax
  • Frequency 2.4 GHz and 5 GHz
  • Signal Rate • 5 GHz: 1201 Mbps†
    • 2.4 GHz: 574 Mbps
  • Wireless Functions • 2×2 (2.4G & 5G) MU-MIMO‡
    • HE80 (80 MHz Bandwidth)‡
    • OFDMA‡
    • Seamless Roaming §
    • Multiple SSIDs (16 SSIDs, 8 on each band)
    • Enable/Disable SSID Broadcast
    • Enable/Disable Wireless Radio
    • Guest Network
    • Automatic Channel Assignment
    • Beamforming
    • Rate Limit
    • Band Steering
    • Load Balance
    • Airtime Fairness
    • Transmit Power Control (Adjust Transmit Power on dBm)
    • QoS (WMM)
    • RADIUS Accounting
    • MAC Authentication
    • Reboot Schedule
    • Wireless Schedule and Statistics
    • Static IP/Dynamic IP
  • Wireless Security
    • Captive Portal Authentication§
    • Access Control
    • Wireless Mac Address Filtering
    • Wireless Isolation Between Clients
    • VLAN
    • Rogue AP Detection
    • 802.1X Support
    • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
  • Transmission Power
    • CE:
      • <20 dBm(2.4 GHz, EIRP)
      • <23 dBm(5 GHz, band1 & band2, EIRP)
      • <27 dBm(5 GHz, band3, EIRP)
    • FCC:
      • <25 dBm (2.4 GHz)
      • <25 dBm (5 GHz)

MANAGEMENT FEATURES

  • Omada App Yes
  • Centralized Management
    • Omada Hardware Controller (OC300, OC200)
    • Omada Software Controller
    • Omada Cloud-Based Controller
  • Cloud Access Yes. Require the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
  • Email Alerts Yes
  • LED ON/OFF Control Yes
  • Management MAC Access Control Yes
  • SNMP v1, v2c, v3
  • System Logging Local/Remote Syslog System Log
  • SSH Yes
  • Web-based Management Yes
  • Zero-Touch Provisioning Yes. Require the use of Omada Cloud-Based Controller.

OTHERS

  • Certification CE, FCC, RoHS, IC
  • Package Content
    • EAP610GP-Desktop
    • Desktop/Wall Mounting Kit
    • Installation Guide
  • System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
  • Environment
    • Operating Temperature: 0–40 ℃ (32–104 ℉)
    • Storage Temperature: -40–70 ℃ (-40–158 ℉)
    • Operating Humidity: 10–90% RH non-condensing
    • Storage Humidity: 5–90% RH non-condensing
MPN: EAP610GP-Desktop
