TP-LINK S385PI 8Mp Outdoo IR Panoramic Bullet Network Cam Vigi Insight

TP-LINK S385PI 8Mp Outdoo IR Panoramic Bullet Network Cam Vigi Insight

Hurry! 2 items left!

$456

Collect 456 Everyday Rewards points

Log in to MyDeal to link your card

Sold & shipped by Radio Parts

Secure ways to pay at checkout

Overview

InSight S385PI VIGI 8MP Outdoor IR Panoramic Bullet Network Camera

180° Panorama View with Huge Vision.
4K (8MP) Ultra HD and IR Range Up to 65.62ft (20m)*¹.
Red-Blue Warning Lights with Stronger Deterrence.
People & Vehicle Analytics*².
Human & Vehicle Classification.
Smart Detection.
Smart Video Enhancement Technology.
Audio and Alarm Interface Available.
IP67 Weatherproof and IK10 Vandal Proof.
H.265+ Compression Technology.

1: Calculations are based on laboratory testing. Actual data is not guaranteed and will vary as a result of client limitations and environmental factors.

2: This feature must be used with VIGI specified software.

3: AI-trigger notification supports playback of specific event clips, notifications triggered by external alarm devices only support live view.

4: Calculations based on laboratory testing using a 3MP VIGI camera, and an actual performance may vary according to the amount of activity recorded, resolution and other variables.

5: The Micro SD card and pole mounting kits are not included in the package.

Specifications

CAMERA	Image Sensor	1/2.7″ Progressive Scan CMOS
Shutter Speed	1/3s to 1/10000s
Slow Shutter
Minimum Illumination	0.005 Lux; 0 Lux with IR Light
Day/Night Mechanism	IR Cut Filter
Day/Night Switch	Unified/Scheduled/Auto
LENS	Type	Fixed Focal Lens
Focal Length	1.65mm
Aperture	F2.0
FOV	Horizontal FOV: 180° Vertical FOV: 86° Diagonal FOV: 180°
Lens Mount	M12
DORI Distance	1.65mm: D: 144.36ft (44m) O: 60.15ft (18.33m) R: 28.87ft (8.8m) I: 14.44ft (4.4m)
Angle Adjustment Range (Manual)	Pan: 0° to 360° Tilt: 0° to 90° Rotation: 0° to 360°
ILLUMINATOR	IR LED	Quantity: 4 Range: 65.62ft (20m)*¹ Wavelength: 850nm
Illuminator On/Off Control	Auto/Scheduled/Always On/Always Off
VIDEO	Max. Resolution	3840 × 2160
Main Stream	Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 3840×2160, 2560×1440, 2304×1296, 2048×1280, 1920×1080, 1280×720 Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Sub-Stream	Frame Rate: 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 848×480, 704×576, 640×480, 640×360, 352×288, 320×240 Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Bit Rate Control	CBR, VBR
Video Compression	Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264
H.264 Type	High Profile
H.264+	Main Stream Supported
H.265 Type	Main Profile
H.265+	Main Stream Supported
Video Bit Rate	Main Stream: 256 Kbps to 8 Mbps Sub-Stream: 64 Kbps to 1024 Kbps
IMAGE	Image Settings	Mirror Brightness Contrast Saturation Sharpness Exposure WDR White Balance Prevent Over-Exposure to Infrared Light HLC Adjustable by Client Software
Image Enhancement	BLC 3D DNR HLC SmartIR
Wide Dynamic Range	120 dB
SNR	≥52 dB
Image Parameters Switch
Privacy Mask	Up to 4 Masks
ROI	4 Regions
OSD Setting
AUDIO	Audio Communication	Two-Way Audio
Audio Input	Built-In Microphone Audio In Interface
Audio Output	Built-In Speaker Audio Out Interface
Audio Compression
Audio Sampling Rate	8KHz
Environment Noise Filtering
Audio Bit Rate	64 Kbps (G.711 alaw)
NETWORK	Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
ONVIF
API	Open Network Video Interface (Profile S/T/G)
Simultaneous Live View	3 × Main Streams 3 × Sub-Streams
Client	VIGI App, VIGI Security Manager, Web UI, VIGI VMS, VIGI Cloud VMS
Web Browser	Google Chrome® 57 and above Firefox® 52 and above Safari® 11 and above Microsoft® Edge 91 and above
Cloud
Security	Password Protection HTTPS Encryption IP Address Filter Digest Authentication
ALARM AND EVENT MANAGEMENT	Smart Event	Intrusion Detection Line-Crossing Detection Region Entering Detection Region Exiting Detection Object Abandoned Detection Object Removal Detection Loitering Detection People Detection Vehicle Detection Abnormal Sound Detection Scene Change Detection
Basic Event	Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts) Video Tampering Detection Exception (Illegal Login) Alarm Input Device
Alarm Linkage	Memory Card Video Recording Upload to FTP Server Alarm Output Device Push Notifications Send to Alarm Server Active Defence-Sound Alarm Active Defence-Light Alarm Email Alarm
Deep Learning Function	People & Vehicle Analytics: Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier*².
INTERFACES	Network Interface	1 × RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Alarm	1 × Alarm In 1 × Alarm Out Red-Blue Warning Lights
Reset Button
Power	DC Power Port
On-board Storage	Built-in Memory Card Slot, supports MicroSD Card, up to 512 GB*⁵.
Built-in Microphone	Yes; Records anything going on within a 16.4ft (5m) radius of the camera.
Built-in Speaker
Audio	1 × Audio In 1 × Audio Out
ENVIRONMENT	Operating Temperature	−30°C to 60 °C
Storage Temperature	−40°C to 60°C
Operating Humidity	95% or Less (Non-Condensing)
Storage Humidity	95% or Less (Non-Condensing)
GENERAL	Power Supply	12V DC ± 5%, Max. 18W, 5.5mm Coaxial Power Plug PoE: 802.3at, Class 4, Max. 21W
Protection	IP67 Weatherproof IK10 Vandal Proof
Material	Metal
Dimensions (L×W×H)	266mm × 100mm × 101mm (10.5″ × 3.9″ × 4″)
Net Weight	1.01 Kg
Package Contents	VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories
Certifications	CE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, Aussie Stock All our stock is kept in our Melbourne based warehouse. Our stock levels are also updated every 10 minutes! So if it says 10 units in stock, you can trust that it is accurate. No PO Boxes or Parcel Lockers At this stage we only use couriers and can only deliver to a road-side address. This means PO Boxes and Parcel Lockers cannot be accepted as StarTrack do not deliver to these addresses. In instances where a PO Box or Parcel Locker address in entered, we may ask for an alternative road-side address, or cancel and refund your order immediately and urge you to replace your order with an alternative delivery address. Delivery times We typically dispatch our goods same day or next day. From there, you can expect 2 - 8 business days Australia wide. Most capital cities can expect 1-2 day delivery times. Any RTS (Return to Sender) orders due to missing or incorrect address information entered by the buyer may incur an additional charge for redelivery.
