Ubiquiti U7 Pro XGS, Black, Ceiling-mounted 8-stream WiFi 7 AP,Dedicated Spectral Scanning Radio,10/5/2.5/1 GbE Support,160 m Coverage,500+ Devices

Image 1
Image 2
Limited Stock
$699

Collect 699 Everyday Rewards points

Log in to MyDeal to link your card
Free Shipping
Sold & shipped by MAD Electronics Australia
Secure ways to pay at checkout

U7 Pro XGS (Black)

Ceiling-mounted 8-stream WiFi 7 AP with dedicated spectral scanning radio and 10/5/2.5/1 GbE support.

8-Spatial Stream WiFi 7 with 6 GHz Support Up to 160 m2 (1,750 ft2) Coverage 500+ Connected Devices 6 GHz Radio 10/5/2.5/1 GbE Uplink Power Method: PoE++ Technical Specs Overview Dimensions O215 x 32.5 mm (O8.5 x 1.3") Colour Black WiFi Standard WiFi 7 Spatial Streams 8 Coverage Area 160 m2 (1,750 ft2) Max. Client Count 500+ Uplink 10 GbE Mounting Ceiling, Wall (Lite Mount Included) Power Method PoE++ Performance MIMO 6 GHz: 2 x 2 (DL/UL MU-MIMO)
5 GHz: 4 x 4 (DL/UL MU-MIMO)
2.4 GHz: 2 x 2 (DL/UL MU-MIMO) Max. Data Rate 6 GHz: 5.8 Gbps (BW320)
5 GHz: 8.6 Gbps (BW240)
2.4 GHz: 688 Mbps (BW40) Antenna Gain 6 GHz: 6 dBi
5 GHz: 6 dBi
2.4 GHz: 4 dBi Max. TX Power 6 GHz: 24 dBm
5 GHz: 29 dBm
2.4 GHz: 23 dBm Max. BSSIDs 8 per Radio Supported Data Rates 802.11be (WiFi 7):
6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320)
5 GHz: 7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)

802.11ax (WiFi 6):
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

802.11ac (WiFi 5):
6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11n:
6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) Features Wireless Meshing Yes Band Steering Yes 802.11v BSS Transition Management Yes 802.11r Fast Roaming Yes 802.11k Radio Resource Management (RRM) Yes Advanced Radio Management Yes Passpoint (Hotspot 2.0) Yes Captive Hotspot Portal Custom Branding Landing Page: Yes
Voucher Authentication: Yes
Payment-Based Authentication: Yes
External Portal Server Support: Yes
Password Authentication: Yes
Guest Network Isolation: Yes Private Pre-Shared Key (PPSK) Yes WiFi Speed Limiting Yes Client Device Isolation Yes WiFi Schedules Yes RADIUS over TLS (RadSec) Yes Dynamic RADIUS-assigned VLAN Yes Hardware Max. Power Consumption 29W Supported Voltage Range 42.5-57V DC Networking Interface (1) 10 GbE RJ45 port Weight 800 g (1.8 lb) Management Ethernet Enclosure Material UV-stabilised polycarbonate, aluminium alloy Mount Material Stainless steel (SUS304), galvanised steel (SGCC) LEDs System: White/Blue Channel Bandwidth HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz) NDAA Compliant Yes Certifications CE, FCC, IC Ambient Operating Temperature -30 to 40o C (-22 to 104o F) Ambient Operating Humidity 5 to 95% noncondensing Software Application Requirements UniFi Network
Version 9.1.120 and later (U7 Pro XGS - Black)

MPN: NHU-U7-PRO-XGS-B
