Ubiquiti UniFi U7-Outdoor (BE5000) Dual-Band 4-Stream Wi-Fi 7 Access Point with 2.5GbE Port (PoE+ 19W) [U7-Outdoor]

Image 1
Image 2
Image 3
Image 4
Limited Stock
$422.23

Collect 422 Everyday Rewards points

Log in to MyDeal to link your card
Sold & shipped by F Digital Direct Import
Secure ways to pay at checkout
Ubiquiti UniFi U7-Outdoor (BE5000) Dual-Band 4-Stream Wi-Fi 7 Access Point with 2.5GbE Port (PoE+ 19W)

All-weather WiFi 7 AP with 4 spatial streams, an integrated directional super antenna, and versatile mounting options.
- WiFi 7
- 4 spatial streams
- 465 m² (5,000 ft²) open space coverage with the integrated directional super antenna
- Software-switchable from internal directional to included external omni antennas
- 200+ connected devices
- Powered using PoE+
- 2.5 GbE uplink
- Versatile wall and pole mounting
- Weatherproof (outdoor exposed)

Mechanical
Dimensions
170 x 208 x 54.5 mm (6.7 x 8.2 x 2.1")
Weight
1.2 kg (2.6 lb)
Enclosure material
UV-stabilized polycarbonate, aluminum alloy
Mount material
Polycarbonate, SGCC steel
Pole mount diameter
25–60 mm (1–2.36") on pipe outer diameter
Wind survivability
74.6 N at 200 km/h (16.8 lbf at 125 mph)
Weatherproofing
IPX6
Hardware
Networking interface
(1) 1/2.5 GbE RJ45 port
Management interface
Ethernet
Power method
PoE+
Power supply
UniFi PoE Switch
Supported voltage range
42.5—57V DC
Max. power consumption
19W
Max. TX power
2.4 GHz
5 GHz
6 GHz
23 dBm
26 dBm

MIMO
2.4 GHz
5 GHz
6 GHz
2 x 2 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)

Max. data rate
2.4 GHz
5 GHz
6 GHz
688 Mbps (BW40)
4.3 Gbps (BW240)

Antenna gain
2.4 GHz
5 GHz
6 GHz

Directional internal: 8 dBi/External omni: 3 dBi
Directional internal: 12.5 dBi/External omni: 4 dBi

Antenna beamwidth
2.4 GHz
5 GHz
6 GHz
90°
45°

Antennas
(1) Directional internal antenna
(2) External omni antennas
(2) RP-SMA connectors for external antenna
LEDs
(1) Power: white/blue
(4) Mesh signal: blue
Button
Factory reset
Mounting
Wall, ceiling, pole (Included)
Ambient operating temperature
-30 to 60° C (-22 to 140° F)
Ambient operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Software
WiFi standards
802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7)
Wireless security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
BSSID
8 per radio
VLAN
802.1Q
Advanced QoS
Per-user rate limiting
Guest traffic isolation
Supported
Concurrent clients
200+
Supported Data Rates
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b
1, 2, 5.5, 11 Mbps
802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11be (WiFi 7)
7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
Application Requirements
UniFi Network
Version 8.3 and later
- MPN: U7-Outdoor

GTIN: 810084695531
