Ubiquiti UniFi USW-Flex-2.5G-8-PoE 10-Port 10G L2 Managed PoE-Passthrough PoE Switch (76W) - 10GbE PoE+++/SFP+ Combo x1, 2.5GbE PoE++ x8 (No PSU included) [USW-Flex-2.5G-8-PoE]

Image 1
Image 2
Image 3
Hurry! 1 items left!
$422.83

Collect 422 Everyday Rewards points

Log in to MyDeal to link your card
Sold & shipped by F Digital Direct Import
Secure ways to pay at checkout
Ubiquiti UniFi USW-Flex-2.5G-8-PoE 10-Port 10G L2 Managed PoE-Passthrough PoE Switch (76W) - 10GbE PoE+++/SFP+ Combo x1, 2.5GbE PoE++ x8 (No PSU included)

Flexible, 8-port 2.5 GbE PoE++ switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered with PoE+++ or an AC power adapter.

Dimensions
212.9 x 99.4 x 33.5 mm
(8.4 x 3.9 x 1.3")
Port Layout
2.5 GbE RJ45

8 (All PoE++)
(2.5G/1G/100M/10M)

10 GbE RJ45

1 (PoE+++)
(10G/5G/2.5G/1G/100M)

10G SFP+
1
Max. PoE Output
Up to PoE++
Total PoE Availability
PoE+++ input: 76W
PoE++ input: 46W
PoE+ input: 16W
210W AC adapter input: 196W
Form Factor
Compact Desktop, wall, DIN, magnetic
Performance
Switching Capacity
60 Gbps
Total Non-Blocking Throughput
30 Gbps
Forwarding Rate
45 Mpps
Supported VLANs
256
MAC Address Table Size
4,000
Layer 2 Features
STP & RSTP
Yes
Egress Rate Limit
Yes
Flow Control
Yes
Storm Control
Yes
Multicast & Broadcast Rate Limiting
Yes
Port Isolation
Yes
Port Mirroring
Yes
Jumbo Frames
Yes
Loop Protection
Yes
Hardware
PoE Ports
PoE++
8
Max. PoE Wattage per Port by PSE
PoE
15.4W
PoE+
32W
PoE++
64W
Max. Power Consumption
14W (Excluding PoE output) with PoE input
17W (Excluding PoE output) with AC adapter input
210W (Including PoE Output)
Power Method
(1) AC/DC adapter (Excluded)
(1) PoE+++
Power Input Method
DC Input
PoE
Supported Voltage Range
50—57V DC/PoE
Management
Ethernet
Weight
567 g (20 oz)
Enclosure Material
Polycarbonate
Mount Material
Polycarbonate
Ambient Operating Temperature
-20 to 45° C (-4 to 113° F)
Ambient Operating Humidity
10 to 90% noncondensing
NDAA Compliant
Yes
Certifications
CE, FCC, IC
Software
Application Requirements
UniFi Network
Version 9.0.114 and later
- MPN: USW-Flex-2.5G-8-PoE

GTIN: 810084695968
