Ursalink Lorawan Remote Iot Client With Digital Input And Relay Output

Image 1
$99.95

Sold Out

Notify me when this product is back in stock

To understand how we handle your personal information, see our Privacy Collection Notice and Privacy Policy.

Shop More Products
Sold & shipped by Crazy Sales Australia

URSALINK LORAWAN AU915/AS923 REMOTE IOT CLIENT WITH DIGITAL INPUT AND RELAY OUTPUT

Ursalink LoRaWAN AU915/AS923 Remote IoT Client with Digital Input and Relay Output. Ursalink UC1114 is designed as a cost-effective industrial machine monitoring device that monitors and controls up to 2 dry contacts and 2 drivable relay outputs. With the aid of Ursalink UC1114, the alarm condition brings attention to engineering personnel immediately. The output can be connected with an alarm indication device, such as a light or horn. The device can give immediate response to the status of both the input and output conditions. A LoRaWAN module is embedded in the Ursalink UC1114.

Ursalink is a professional IoT company that leverages the top trending technologies to simplify the process of data collection, storage and retrieval in order to accomplish the goal: connecting "things" to the Cloud.

FEATURES

Easy operation anywhere and anytime

2 digital inputs, connected with up to 2 dry contact devices

2 relay drivable outputs

Reliable performance with built-in watchdog

Customizable conditions, programmable actions

Send uplink alert messages according to user-defined conditions

Automatic switching of field devices at set times

Send and receive messages via LoRaWAN technology

Comply with the LoRaWAN Class C protocol

Support star network and mesh network

High Rx sensitivity and adjustable Tx power

Up to 10km communication distance with omni-directional antenna

SPECIFICATIONS

Manufacturer's Code UC1114-AS923

Antenna 50 Ohm SMA Antenna Interface

Frequency Band AU915, AS923

Sensitivity -147 dBm @300bps

Output Power 20dBm

Protocol LoRaWAN Class C

Digital Input Opto-isolated depending on voltage, Can accept any DC signals of any type, including: DC Voltage (3-24 V)

Digital Output 2 x SPDT Relay Contact Rating: 3Amp DC (Max: 30 V) or 3Amp AC (Max: 250 V)

IO Connector type Screw Terminals

DC Power Supply 5-24 VDC

Operating Temperature -40degC to +70degC

Relative Humidity 0% to 95% (non- condensing)

Dimensions 79 x 60 x 24 mm

PACKAGE CONTENTS

1 x Ursalink Lorawan Remote Iot Client With Digital Input And Relay Output
1 x Terminal Block
