Range - 9.5-95VDC

Bluetooth inside
With Bluetooth built-in, the BMV Smart is ready for the Internet of Things (IoT) era. With Bluetooth being implemented in most other Victron Energy products, wireless communication between products will simplify
system installation and enhance performance.

Download the Victron Bluetooth app

Use a smartphone or other Bluetooth enabled device to

customise settings
monitor all important data on single screen
view historical data, and to
update the software when new features become available.

Battery voltage, current, power, ampere-hours consumed and state of charge

Remaining time at the current rate of discharge

Programmable visual and audible alarm

Programmable relay, to turn off non critical loads or to run a generator when needed

500 Amp quick connect shunt and connection kit

Shunt selection capability up to 10.000 Amps

VE. Direct communication port

Stores a wide range of historical events, which can be used to evaluate usage patterns and battery health

Wide input voltage range: 6,5 - 70V

High current measurement resolution: 10 mA (0,01A)

Additional input to measure voltage (of a second battery), temperature or midpoint voltage, and corresponding alarm and relay settings
