FBC4022GL
Xiaomi Mi Electric Scooter Essential 20km Long Range FBC4022GL
OVERVIEW
Mi Electric Scooter Essential is designed for people who want to keep it light and easy. It uses a low-density, high-strength aerospace grade aluminum alloy, so that the net weight of the vehicle is only 12kg, making it easy to carry. Mi Electric Scooter Essential features a minimalist design. Riding it will make you feel alive and make passersby envious.
FEATURES
-
3 seconds fast folding
Thanks to the ingenious structural design, Mi Electric Scooter Essential can be folded in only 3 seconds. At a folded height of just 49cm, the vehicle is compact and takes up less space, making it easier to carry.
-
Minimalist controls, smart travel
-Multi-functional dashboard
Accurate display of speed and various ride stats
-Comfortable foam grip
Increased comfort and improved control experience
-One button for multiple functions
Just one button to turn the scooter on/off, switch speed modes, and turn on the headlight
-Sensitive hand throttle
Throttle control, moderate resistance, linear acceleration
-
Smart connection to unlock new functions
Connect the Mi Electric Scooter Essential to the Mi Home app to check riding stats, battery status and to upgrade firmware.
-
New energy recovery system Riding can also "power up"
The kinetic energy recovery system (KERS) has been fully upgraded. When braking or releasing the throttle while driving, the energy conversion is more efficient, further increasing battery life.
-
Brake once, activate two brakes
An E-ABS anti-lock brake system for the front wheel and a large disc brake for the rear wheel. Both are activated at the same time, shortening the braking distance, making driving safer
-
New generation 8.5" pneumatic tires
The puncture resistance and robustness have been comprehensively improved and the performance of the explosion-proof tires has also been greatly optimized. The durability of the 8.5" tires has been increased by up to 3 times. Not only does it make for a smooth ride on flat roads, it is also very comfortable to ride on non-paved roads like gravel, dirt roads, and grass.
-
Large taillight
The new taillight is larger in size making it easier for others to spot, allowing you to drive safer at night
-
Upgraded headlight No dazzle, more comfortable lighting
The brand-new 2W headlight has high brightness and the irradiation distance reaches 10 meters. The lighting angle design has been optimized to stay below the line of sight to prevent headlight dazzle
-
Front, side and tail reflectors for better visibility
Reflectors have been added on the front, on the sides, and to the tail light, further enhancing night visibility to keep you safe while driving at night.
*Tested under the conditions that power is sufficient, with a 75kg load, at 30°C, 70% humidity, level 3 wind speed, 50psi tire pressure, on a level road, in pedestrian mode below 15km/h uniform velocity. Actual results may vary based on differences in temperature, load, wind speed, road conditions and other factors.
*Based on the typical walking speed of 1m/s, compared to the 3.6km/h riding speed of Standard mode (S).
*It is not recommended to use cruise control when exceeding 15km/h speed, where roads are windy, in areas with heavy traffic, or during or after precipitation.
*All above data was obtained from Ninebot labs. Actual results may vary based on differences in use conditions.
*Before purchasing, please carefully read the Mi Electric Scooter Essential user manual and legal notice. Be sure to abide by local laws and regulations when using Mi Electric Scooter Essential.
SPECIFICATION
-
Max. speed: 20km/h (Max speed for each mode: Pedestrian mode: 5km/h; D: 15km/h; S: 20km/h)
-
General range: 20km
-
Max. climbing angle: 10°
-
Braking: E-ABS and disc brake
-
Rated power: 250W
-
Max. power: 500W
-
Tires: 8.5" front and rear pneumatic tires
-
Controller undervoltage protection: 29V ± 0.5V
-
Controller current limit: 17A±0.5A
-
Motor type: Brushless low speed DC motor
-
Max.load: 100kg
-
Rider height: 120cm-200cm
-
Rider age: 16-50
-
Working temperature: -10°C to 40°C
-
Storage temperature: -20°C to 45°C
-
IP-rating: IP54
-
Charging time: 3.5 hours
AC power cable
-
Plug type: 2 straight prong
-
Tail type: 8-shape
-
AC wire: H05VVH2-F
-
AC cable length: 2.0m
Adapter specs
-
Input voltage: 100-240VAC 50/60Hz
-
Input current: 2A MAX
-
Output voltage: 42VDC
-
Output current: 1.7A
-
Output power: 71W
-
DC cable length: 2m
-
DC cable port type: Custom Φ8.0*1.6mm
Battery specs
-
Battery type: Lithium ion battery
-
Battery model: NE1002-H
-
Maximum charging voltage: 42VDC
-
Rated voltage: 36VDC
-
Rated capacity: 5100mAh /183Wh
-
Charging temperature range: 0°C — 40°C
-
Discharge temperature range: -20°C — 50°C
-
Storage time: Approx. 13 months
-
Battery weight: 1.1kg
-
Cyclical lifetime: 500 charging cycles with power maintained above 70%
Package contents
- Mi Electric Scooter Essential
- Power adapter
- Hexagon wrench
- Extended nozzle adapter
- Screw
- User manual
- Important information
- Specifications
IMPORTANT NOTICE
- The laws around the use of scooters on public lands, roads and areas vary from state to state.
- We recommend you always check your local council and road traffic laws prior to using a scooter to ensure you are aware of any restrictions that may affect the use of motorised vehicles.
- Always use appropriate protective riding equipment such as an approved helmet and suitable clothing.
