20 Channel / 16 Channel x PoE 4K Network Video Recorder

This 20 Channel / 16 Channel x PoE 4K Network Video Recorder offers 5MP resolution recording at 25fps for up to 20 cameras (or 12ch of 4K 25fps). For ease of installation, 16 dedicated PoE ports are in-built. It utilises H.264/H.265+ compression to maximise your hard disk space and has wide camera compatibility with ONVIF 2.4 support. Recording can be manually set, sch

This 20 Channel / 16 Channel x PoE 4K Network Video Recorder offers 5MP resolution recording at 25fps for up to 20 cameras (or 12ch of 4K 25fps). For ease of installation, 16 dedicated PoE ports are in-built. It utilises H.264/H.265+ compression to maximise your hard disk space and has wide camera compatibility with ONVIF 2.4 support. Recording can be manually set, scheduled or triggered by motion detection. Supports four internal hard disks, maximum storage 32TB. Hard drives sold separately.



• H.264+/265+ compression
• 4K HDMI monitor output
• Recording 20 channels up to 5MP  25fps per ch
• Supports iOS and Android remote viewing
• 16 x 15.4W PoE network interfaces
• Four internal SATA interface, max 32TB
• Remote control & mouse
• USB backup
• Dedicated network interface
• Audio input & output
• ONVIF 2.4 support
• System
• Main Processor: ARM Cortex A7 Processor
• Operating System: Embedded LINUX
•
• Video
• Input: 25CH (4096×2160, 2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc)
• Output:1 VGA, 1 HD
•
• Audio
• Input:1 Port RCA
• Output: 1 Port RCA(Linear, 1kΩ)
• Audio Bit Rate: 64kbps
• Audio Compression standard: G711u, G711a
•
• Alarm
• Sensor Input: 16CH Input
• Output: 4CH Output
• Motion Detection: 25 Channel, MD Zones: 396 (22 × 18)
• Trigger Events: Recording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output
•
• Display
• HD Output: Resolution:4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• VGA: Resolution:1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• Display Split: 25CHxD1/16CHxD1/9CHxD1/4CHxD1/1CHx1080P/1CHx3MP/1CHx4MP/1CHx5MP/1CHx4k/1CHx12MP
• Digital Zoom: YES
• OSD: Camera Title, Time, Recording, Motion Detection
•
• Recording
• Video Compression: H265/H264/H265+/H264+
• Resolution: 4k(4096×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536),1080P(1920×1080),960P(1280x960),720P(1280×720),D1 (720×576/720×480)

• H.264+/265+ compression
• 4K HDMI monitor output
• Recording 20 channels up to 5MP  25fps per ch
• Supports iOS and Android remote viewing
• 16 x 15.4W PoE network interfaces
• Four internal SATA interface, max 32TB
• Remote control & mouse
• USB backup
• Dedicated network interface
• Audio input & output
• ONVIF 2.4 support
