AX5400 MESH WIFI 6 EXTENDER
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
,gravity=Center,allowExpansion)
Collect 238 Everyday Rewards points
Collect 238 Everyday Rewards points
1: Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed. They will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead; and 3) client limitations, including rated performance, location, connection, quality, and client condition.
2: Omada Mesh, Seamless Roaming, and Captive Portal require an Omada SDN controller.
HARDWARE FEATURES | Interface | 1 × Gigabit Ethernet Port |
---|---|---|
Physical Security Lock | No | |
Button | Reset, LED | |
Power Supply | 100~240V, 50/60Hz | |
Max. Power Consumption | 18W | |
Antenna |
| |
Mounting | Plug in | |
WIRELESS FEATURES | Coverage | 140m (1500ft²)*⁵ |
Concurrent Clients | 250+*⁴ | |
Wireless Standards | IEEE 802.11ax/ac/n/g/b/a | |
Frequency | 2.4 GHz and 5 GHz | |
Signal Rate |
| |
Wireless Functions |
| |
Wireless Security |
| |
Transmission Power | CE:
| |
MANAGEMENT FEATURES | Omada App | Yes |
Centralised Management |
| |
Cloud Access | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. | |
Email Alerts | Yes | |
LED ON/OFF Control | Yes | |
Management MAC Access Control | Yes | |
SNMP | v1, v2c, v3 | |
System Logging Local/Remote Syslog | Yes | |
SSH | Yes | |
Web-based Management | Yes | |
Management VLAN | Yes | |
Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. | |
ENVIRONMENT | Operating Temperature | 0°C~40°C (32°F~104°F) |
Storage Temperature | −40°C~70°C (−40°F~158°F) | |
Operating Humidity | 10~90% RH non-condensing | |
Storage Humidity | 5~90% RH non-condensing | |
GENERAL | Dimensions (W×D×H) | 160mm × 80mm × 37.8mm (6.3″ × 3.1″ × 1.5″) |
Package Contents |
| |
Certification | CE, FCC, IC, RoHS, UL |
1: Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed. They will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead; and 3) client limitations, including rated performance, location, connection, quality, and client condition.
2: Omada Mesh, Seamless Roaming, and Captive Portal require an Omada SDN controller.
3: Use of Wi-Fi 6 (802.11ax) and its features, including OFDMA and 1024-QAM, require clients to support the corresponding features.
4: The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
5: Coverage value is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.
